Overview
The Pro Comp K4021T is a 6-inch stage 1 lift kit with PRO-X front and rear shocks for the 1999–2004 Ford F-250 Super Duty and the 1999–2004 Ford F-350 Super Duty. The lift height range is 6 to 7 inches, and both shocks are included.
The rear uses a block and spacer design with block and U-bolt components and add-a-leaf hardware. It is a direct fit for the Super Duty models in the Harley-Davidson Edition, King Ranch, Lariat, XL and XLT versions.
Key features
- 6-inch stage 1 lift for 1999–2004 Super Duty pickups
- PRO-X front shocks and PRO-X rear shocks
- Block and U-bolt rear lift with add-a-leaf hardware
- Lift height range of 6 to 7 inches
Driveline and alignment after a lift
A 6-inch lift on a Super Duty raises the axle relative to the transmission and transfer case, which changes driveline angles. Steep angles can cause vibration at highway speed and extra wear on universal joints, so measuring the angles after installation is part of a finished job.
Front alignment also moves when the front geometry changes. Caster and toe should be set once the truck is at its new ride height. The rear block lift should be checked for driveline clearance at full droop, and brake hoses should be checked for tension when the suspension is fully extended.
- Measure driveline angles once the lift is complete
- Set front alignment at the new ride height
- Check brake hoses at full suspension droop
- Recheck U-bolt torque after the first trip
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | K4021T |
| Suspension type | Lift kit, stage 1 |
| Lift height | 6 inches, listed range 6–7 inches |
| Front shocks | PRO-X |
| Rear shocks | PRO-X, included |
| Rear lift method | Block/spacer with block and U-bolt and add-a-leaf |
| Shocks included | Yes |
Vehicle fitment
It fits the 1999–2004 Ford F-250 Super Duty and the 1999–2004 Ford F-350 Super Duty, including the Harley-Davidson Edition, King Ranch, Lariat, XL and XLT versions.
The fit covers 1999 through 2004 Super Duty models. Compare your truck’s year, model and trim with this fit before you buy.
Installation notes
A 6-inch lift on a Super Duty changes the driveline angles and the front alignment, so have both checked after installation, and confirm the rear block lift clears the driveline.
What’s included
PRO-X front and rear shocks, and the block and U-bolt rear lift components with add-a-leaf hardware.
