Overview
The Pro Comp K4037BP is a 6-inch stage 1 coil spring lift with Pro Runner front shocks. It fits 2005–2007 Ford F-250 Super Duty and F-350 Super Duty trucks, with a lift height range of 5 to 6.99 inches.
This is the Pro Runner front shock version of the K4037B. The front uses coil springs with radius arm brackets, and the rear is lifted with a block and U-bolt kit with add-a-leafs. Sway bar links, bump stop extensions, brake line extension brackets and a pitman arm are included.
Key features
- 6-inch lift, stage 1
- Pro Runner front shocks
- Front coil springs with radius arm brackets
- Front sway bar links and bump stop extensions
- Pitman arm steering correction
- Brake line extension brackets
Things to know first
Before upgrading a front shock, consider how the truck will be used. A Pro Runner style shock is generally tuned for controlled damping on rough surfaces, which suits towing or loaded work. Pair it with the radius arm brackets and coil springs, since a shock tuned for a different spring rate can feel too firm or too soft on a lifted front end.
Look at the rest of the front end at the same time. Sway bar links, bump stop extensions and the pitman arm carry the new loads, so check their bushings and joints during the install. Ask for a steering check after the alignment. Rear block and U-bolt parts settle with use, so retighten them after the first drives and inspect the add-a-leafs for uneven wear.
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | K4037BP |
| UPC | 70000637839 |
| Lift | 6 inches, stage 1 |
| Lift height range | 5 to 6.99 inches |
| Suspension type | Radius arm |
| Front lift | Coil springs with radius arm brackets |
| Rear lift | Block, U-bolts and add-a-leaf |
| Steering correction | Pitman arm |
| Front shocks | Pro Runner |
Vehicle fitment
The kit fits 2005–2007 Ford F-250 Super Duty and F-350 Super Duty trucks. Ford trucks from other model years fall outside this fit.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Set the front alignment after the radius arm brackets are fitted, and check the pitman arm centering once the front is complete. The block and U-bolt rear lift also changes the driveline angles, so check them afterwards.
What’s included
The kit includes front coil springs, radius arm brackets, sway bar links, bump stop extensions, brake line extension brackets, a pitman arm, a rear block and U-bolt kit with add-a-leafs and Pro Runner front shocks.
