Pro Comp 5.5 Inch Rear Lift Block – 52560

Pro Comp Suspension

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Pro Comp Suspension 5.5 inch rear lift block, part number 52560
  • Sold in pairs, two riser blocks per package
  • For rear leaf spring suspensions only
  • Fit depends on your rear leaf spring setup and axle.

Description

Overview

The Pro Comp 52560 is a 5.5 inch rear lift block for leaf spring vehicles, sold in pairs. A riser block raises the rear axle on its leaf spring pack, which lifts the rear of the vehicle.

Riser blocks are intended for the rear of a leaf spring vehicle only and must not be installed on the front.

Key features

  • 5.5 inch rear lift height
  • Sold as a pair of riser blocks
  • Intended for the rear of a leaf spring vehicle only

Rear clearance and driveline changes

A riser block raises the rear axle on its leaf spring pack, so the rear of the vehicle sits higher and the geometry of the suspension changes. Shock length, brake hose reach, and the angle of the driveshaft can all be affected. Before installing a pair of blocks, measure the existing clearance at the tires, fenders, and brake lines so you know where the limits are.

Because the blocks sit between the axle and springs, the U-bolts carry the load that holds the lift in place. Check the tightness of the hardware after the first drives and periodically afterward, especially on rough ground. Look for signs of rubbing on the tires, fenders, and brake lines, and address any contact before it wears a part.

  • Measure tire-to-fender clearance at full compression
  • Check brake hose length after lifting
  • Confirm shock length suits the new height
  • Re-check U-bolt torque after the first drives

Specifications

Brand Pro Comp Suspension
Part number 52560
UPC 614901201208
Type Rear lift block (riser block)
Lift height 5.5 in
Quantity 2 per pack
Position Rear only

Vehicle fitment

It is for rear leaf spring suspensions. Check your leaf spring setup, axle and rear clearance before ordering.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Install the blocks on the rear only. Use U-bolts sized for the 5.5 inch block and your axle, since mounting hardware is not included.

What’s included

Two rear riser blocks per package.

Not included: U-bolts and other mounting hardware are not included with this pair.

SKU: EXP52560 Category:

Specification

Shipping weight 30.00 lbs
Package dimensions 18.00 × 12.00 × 6.00 in
brands

Questions & Answers

Can the Pro Comp 52560 lift block go on the front of a vehicle?

No. Riser blocks must not be installed on the front of a vehicle. The 5.5 inch block is intended only for the rear of a leaf spring vehicle.

How many riser blocks come in one Pro Comp 52560 package?

Two. The 52560 is sold in pairs, so one package provides a block for each rear leaf spring pack on the vehicle.

What lift height is the Pro Comp 52560?

It is a 5.5 inch rear lift block, the height given in both the product name and the specifications for this pair of riser blocks.

Do riser blocks change driveline angle?

Yes. Raising the axle on riser blocks changes the angle of the driveshaft, so check it after installation. Shock length, brake line reach and sway bar links may also need attention. Recheck clearances after the first drives over rough ground to confirm nothing is rubbing.
