Overview
The Power Stop Evolution JBR1389XPR (part number PSTJBR1389XPR) is a pair of rear drilled and slotted brake rotors for the 2010–2015 Lexus RX350 and RX450h and the 2014–2019 Toyota Highlander.
The rotors are solid cast iron with 5 lugs and a slotted and cross-drilled face. Power Stop says each rotor is machined and mill-balanced, with a silver zinc dichromate coating to help prevent rust and corrosion.
Solid rotors have a single disc with no cooling vanes between the faces, which is a common layout for rear brakes. The JBR1389XPR keeps that solid design and adds drilled holes and slots to the friction surface. Because it is a rear part, the front axle of these vehicles uses a different rotor.
Key features
- Precision drilled holes allow rotor cooling during hard use
- Rounded slots wipe away gas and debris and keep a clear contact patch on the rotor face
- Silver zinc dichromate plating helps prevent rust and corrosion
- Each rotor is machined and mill-balanced
- Maximum run-out 0.0032 in (0.08 mm) and maximum DTV tolerance 0.0005 in (0.0125 mm)
- Solid rear rotor design, 5 lugs
Rear brake service on crossovers
Rear rotors on these crossovers carry less braking load than the fronts, but they still wear and can rust when a vehicle sits. Solid rotors with drilled holes and slots keep the friction face clear and handle heat well in normal driving. Rust on the friction face is often a sign that the pads need attention.
Replace both rear rotors together and use fresh pads so the pair wears evenly. Clean the hub face and check the parking brake mechanism while the wheels are off, since a sticking parking brake can overheat one side and wear a new rotor unevenly.
- Measure thickness against the minimum cast into the rotor
- Look for rust bloom on the friction face after storage
- Re-torque the lug nuts after the first short drive
Specifications
| Brand | Power Stop |
|---|---|
| Part number | PSTJBR1389XPR |
| Product type | Rear brake rotors, drilled and slotted |
| Disc material | Cast iron |
| Disc design | Solid |
| Position | Rear |
| Number of lugs | 5 |
| Coating | Coated (silver zinc dichromate) |
| Maximum run-out | 0.0032 in (0.08 mm) |
| Maximum DTV tolerance | 0.0005 in (0.0125 mm) |
| Quantity | 2-wheel set |
| Fit | Direct fit |
Vehicle fitment
It fits the 2010–2015 Lexus RX350 in Base and F Sport, the 2010–2015 Lexus RX450h in Base, and the 2014–2019 Toyota Highlander in LE, LE Plus, SE, XLE, Limited and Limited Platinum, plus the Hybrid LE, Hybrid XLE, Hybrid Limited and Hybrid Limited Platinum. Lexus RX models from 2016 on and Highlanders before 2014 are not covered. Confirm the year, model and trim against your vehicle before ordering.
Lexus RX models from 2016 on and Highlanders before 2014 are not in that list. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Install both rear rotors together and fit fresh pads, since a new rotor face needs matching pad material to bed in evenly.
What’s included
Two rear rotors for one axle.
Not included: Brake pads and mounting hardware.
