Select your vehicle

Fabtech 3″ Sport Lift Kit with Shock Extensions – K4159

Fabtech

Shop Jeep Gladiator Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 3-inch Sport lift kit with shock extensions for 2020–2026 Jeep Gladiator models
  • Dual rate American made front coil springs and rear coil spring spacers
  • Four bump stop extensions and extended, urethane bushed sway bar links
  • Installs in a couple of hours

Description

Overview

The Fabtech K4159 is a 3-inch Sport lift kit with shock extensions for 2020 to 2026 Jeep Gladiator models. The Sport kit offers more ride height and improved suspension performance at a moderate price, and installation takes a couple of hours.

The front uses American made dual rate coil springs. The first stage of the spring gives a soft ride with room to extend for extra travel, and the second stage carries the vehicle’s payload and absorbs large impacts at higher speeds. The rear receives coil spring spacers that keep the factory ride and load carrying capacity, and they add a 1-3/4 inch height to help level the stance.

Key features

  • 3-inch lift height with dual rate American made front coil springs
  • Extended travel from the first spring stage for off-road use
  • Rear coil spring spacers of 1-3/4 inch
  • Four bump stop extensions that use the factory bump stops
  • Extended front and rear sway bar links with urethane bushings
  • Sway bar links that stay within the factory operating planes
  • Includes shock extensions.

Driveline and alignment after lifting

A lift changes the angles the driveline and suspension operate at, so it helps to inspect them after the job is done. Extended sway bar links keep the bars within their operating range, which reduces the bind that can occur at full extension. Check that the links move freely through the full travel range.

Dual rate springs give a softer first stage for daily driving and a firmer second stage when the vehicle carries load. Pay attention to how the truck rides when loaded with gear or a trailer. Re-check the alignment once the new height has settled, since the front geometry can shift slightly during the first drives.

  • Check driveline angles after the install
  • Re-torque bolts after the first few drives
  • Confirm clearance at full steering lock
  • Recheck alignment once the height has settled

Specifications

Brand Fabtech
Part number FABK4159
Lift height 3 inches
Lift height range 0 to 3.5 inches
Front springs Dual rate coil springs, American made
Rear spacer height 1-3/4 inches
Bump stop extensions Four
Sway bar links Extended front and rear, urethane bushings
Shocks No shock absorbers are included with this kit.
Fitment type Direct fit

Vehicle fitment

It fits 2020 to 2026 Jeep Gladiator models in the 80th Anniversary, High Altitude, Launch Edition, Overland, Rubicon, Sport, Sport S, Willys and Willys Sport versions.

Wrangler models do not fit this kit, and Gladiator models from before 2020 are not covered. Check your vehicle’s year, model and trim before ordering.

Installation notes

The extended sway bar links keep the bars within their operating planes and prevent over-center bind at full extension travel. A 3-inch lift changes suspension geometry, so check the driveline angles and the alignment once the install is complete. Fabtech gives a couple of hours for the job.

What’s included

The kit includes the dual rate front coil springs, the 1-3/4 inch rear coil spring spacers, four bump stop extensions and the extended front and rear sway bar links with urethane bushings.

Not included: Shock absorbers. Not included with this kit.

SKU: FABK4159 Categories: ,

Fitment

VehicleYearsTrims
Jeep Gladiator2020–202680th Anniversary, High Altitude, Launch Edition, Overland, Rubicon, Sport, Sport S, Willys, Willys Sport

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the K4159 fit a 2020 Jeep Gladiator?

Yes. It fits 2020 through 2026 Jeep Gladiator models in several versions, including Sport, Sport S, Rubicon and Overland. Confirm your year and version before ordering.

Does this kit include shocks?

No. Shock absorbers are not included with this kit, so shocks would have to be bought separately. Check that any shocks you choose suit the 3-inch lift height.

How much lift does the Sport kit give?

The kit gives a 3-inch lift height, with 1-3/4 inch rear coil spring spacers. The front springs are dual rate, with a soft first stage and a stiffer second stage that carries payload and absorbs impacts.

Should shock absorbers be replaced when lifting?

Many owners replace worn shocks at the same time as a lift, since stock units were tuned for the factory height. Look for leaks, noise and fade on rough roads. Choose shocks with a length that suits the new suspension travel.
