Dana Spicer Dana 35 Nodular Iron Differential Cover – 2020035

Dana Spicer

Shop Dana Spicer Differential Covers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Nodular iron rear cover for Dana 35 axles
  • Aggressive look with trail ready strength
  • Powder coated finish and standard oil capacity
  • Part number D/S2020035

Description

Overview

The Dana Spicer D/S2020035 is a nodular iron rear differential cover for the Dana 35 axle. It has a bold look and a sturdy build, and it covers the gears and locker inside.

Dana is the common axle maker, and the axle type is Dana 35. The cover is powder coated with standard oil capacity. Check your housing against the Dana 35 before installing, since the axle name is the main fit detail.

Key features

  • High strength nodular iron construction
  • Aggressive look matched to trail ready strength
  • Protects the gears and locker
  • Powder coated finish
  • Standard oil capacity

Dana 35 seal and wear checks

The Dana 35 cover has a job beyond keeping oil in. It holds gear oil over the ring and pinion and protects the locker, so any leak or dent deserves attention. Look for oil on the axle tube, wet spots on the brake components, and bent flanges after trail impacts.

A nodular iron cover is heavier than aluminum and tends to stay put under hits, but its powder coat can chip on rock contact. Touch up chips early, because exposed iron starts to rust quickly in wet conditions. Clean the mating face before reinstalling and replace the gasket rather than reusing an old one.

If you add a locker or a larger ring gear later, clearance around the carrier can change. Check that the cover still clears the carrier and axle tube before finalizing your build.

Specifications

Brand Dana Spicer
Part number D/S2020035
Material Nodular iron
Finish Powder coated
Axle location Rear
Axle type Dana 35
Popular axle manufacturer Dana
Oil capacity Standard capacity
Fitment Universal fit

Vehicle fitment

Fit is by axle. It is for the Dana 35 rear axle and is universal fit, with no vehicle models attached.

Confirm your vehicle’s year, model and trim before ordering.

What’s included

Hardware and gaskets are unknown, so check the package contents against your installation before starting.

Questions & Answers

What axle does the Dana Spicer D/S2020035 fit?

It is for the Dana 35 rear axle. No vehicle models, years or trims are known, so identify your axle housing and confirm it is a Dana 35 before installing.

What material is this differential cover?

It is made from nodular iron, which the brand describes as high strength. The cover is powder coated and listed with standard oil capacity.

Is part number 2020035 the same as D/S2020035?

The number is 2020035, and the full part number is D/S2020035. Both refer to the same Dana Spicer cover, so use D/S2020035 when checking part details.

Is it normal for a Dana 35 cover to weep a little oil?

No. A seep at the gasket usually means the bolts are loose, the flange is warped, or the gasket is worn. Re-torque the bolts first, then inspect the sealing face before replacing the gasket.
