Bushwacker Ford Cut-Out Rear Fender Flares (Paintable) – 20012-11

Bushwacker

Shop Bushwacker Fender Flares on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Cut-Out Style rear fender flares for the Ford, pair of rear flares
  • 3.5 inches of width and tire coverage
  • Sheet metal removal maximizes wheel articulation
  • OEM matte black finish that is easy to paint
  • Made in the USA with a limited lifetime warranty

Description

Overview

The Bushwacker Cut-Out Style rear fender flare pair, part 20012-11, is a pair of rear flares for Ford vehicles. Each Cut-Out set is individually designed for the vehicle to maximize off-road wheel travel and maintain adequate tire coverage. This pair adds 3.5 inches of width and tire coverage at the rear.

Cut-Out flares require cutting body sheet metal to reach maximum articulation and coverage for oversized tires. The design gives a smoother appearance and greater strength, and the pair is fastened with a tough rivet installation. It is made in the USA from thick, warp-proof Dura-Flex 2000, and the matte black finish is easy to paint.

Key features

  • Individually designed to maximize off-road wheel travel
  • 3.5 inches of width and tire coverage at the rear
  • Sheet metal removal maximizes wheel articulation
  • Tough rivet installation
  • Warp-proof Dura-Flex 2000 construction, made in the USA
  • OEM matte black finish that is easy to paint

Cutting and rivet install

Rear cut-out flares change the wheel opening, so the work starts before the first cut. Measure the clearance at the tire with the vehicle loaded and at full suspension travel, then mark the cut line with the flare held in place.

The rivet installation is a different step from bolt-on flares, so plan the holes and the rivet positions carefully. Drill and set rivets in the order that keeps the flare aligned, and check the position against the tire after each step.

Cut edges need attention after the install. Deburr them, seal the bare metal with primer and paint, and apply a seam sealer where the flare meets the body. Recheck the rivets after the first wash and after rough trail use.

  • Mark the cut line with the flare held in place
  • Plan rivet positions before drilling
  • Deburr and prime every cut edge
  • Recheck rivets after the first wash

Specifications

Brand Bushwacker
Part number 20012-11
UPC 90689103154
Position Rear
Quantity Pair
Width and coverage 3.5 inches
Material Dura-Flex 2000
Finish OEM matte black, paintable
Front pair part number 20011-11
Warranty Limited lifetime

Vehicle fitment

This pair is made for Ford vehicles in general. Confirm fit for your Ford model year, cab and body style before ordering.

Because no years or models are given, do not assume this pair matches a particular Ford truck or SUV. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Cut-Out flares require cutting body sheet metal, and the pair uses a tough rivet installation. Check the fit on your vehicle before cutting, and mark the cut line for your model first.

What’s included

This is the rear Cut-Out pair. The front pair is part 20011-11.

SKU: B/W20012-11 Category:

Specification

Shipping weight 11.00 lbs
Package dimensions 53.00 × 22.00 × 10.00 in
brands

Questions & Answers

Is this a rear pair or a front pair?

This is a rear pair. The front pair is part 20011-11, so confirm the position on the part number before ordering. Position matters because the two pairs sit at different wheel openings.

Does this pair require cutting?

Yes. Bushwacker says Cut-Out flares require cutting body sheet metal to achieve maximum articulation and tire coverage, so confirm the fit before cutting anything.

Is the rear pair paintable?

Yes. The OEM matte black finish is designed to take paint, so the pair can be painted to match the body. Clean and prime the surface first.

How do I prevent rust at a cut-out edge?

Seal bare metal the same day you cut it, using a rust-inhibiting primer, then topcoat. Deburr the cut edge and apply a seam sealer where the flare meets the body. Recheck the rivets and edges after the first wash and after rough trail use.
