Bilstein 6100 Series Ride Height Adjustable Shock Absorber – 24-322669

Bilstein

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front ride height adjustable shock for 2016–2024 Nissan Titan XD
  • Adjustable ride height range of 0 to 3 in with OE springs
  • 60mm body and large 60mm digressive piston
  • Gas charged coilover design with an eyelet lower mount

Description

Overview

The Bilstein 6100 Series 24-322669 is a front ride height adjustable shock absorber for the 2016–2024 Nissan Titan XD. It is built for trucks and SUVs with a front OE coilover-style suspension and gives an adjustable ride height range of 0 to 3 inches, depending on the application.

The 60mm body has snap-ring grooves that let the spring seat sit at different heights, and that position sets the front ride height. The unit uses a large 60mm digressive piston, which Bilstein says gives a smoother ride while offering more control over rough terrain. It is a gas charged coilover design with an OEM top mount and an eyelet bottom mount.

The 6100 is built for increased durability and heat dissipation, which suits trucks that run on rugged roads and in harsh conditions.

Key features

  • Front ride height range of 0 to 3 in with OE springs
  • Snap-ring grooves for spring seat positions
  • 60mm body and large 60mm digressive piston
  • Gas charged coilover design
  • OEM top mount and eyelet bottom mount

Adjusting ride height safely

A coilover style ride height adjustment works by moving the spring seat along the body, which changes both the spring preload and the front geometry. Set the position in small steps, then drive the truck and check how it handles braking, cornering and rough surfaces. A change in ride height also changes the front axle angle, which affects steering feel and tire wear.

Adjustable shocks work best when the rest of the front end is in good order. Inspect the upper mounts, bushings and springs before adjusting the seat, since worn parts can make a new setting feel loose or noisy. After any change, have the front alignment checked and watch the tires for uneven wear over the first few weeks of driving.

  • Note the groove position before changing it
  • Check the lower eyelet for play once the truck is back on its wheels
  • Recheck the spring seat after rough off-road use

Specifications

Brand Bilstein
Part number 24-322669
Shock series 6100 Series (ride height adjustable)
Position Front
Shock type Coilover, gas charged
Body diameter 60mm
Piston 60mm digressive
Front lift range 0 to 3 in
Top mount OEM
Bottom mount Eyelet
Fitment type Direct fit

Vehicle fitment

It is a front shock for the 2016 through 2024 Nissan Titan XD.

The standard Nissan Titan, Titan models before 2016 and after 2022, and other Nissan trucks are not on this list. Confirm your vehicle’s year, model and trim before ordering.

What’s included

One front ride height adjustable shock absorber.

Installation notes

Set the spring seat in the groove that gives the ride height you want, then check the front alignment once the truck is back on its wheels.

Fitment

VehicleYearsTrims
Nissan Titan XD2016–2024PRO-4X, Platinum Reserve, S, SL, SV

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the Bilstein 24-322669 fit a 2018 Nissan Titan XD?

Yes. It is a front shock for the 2016 to 2024 Nissan Titan XD, so a 2018 model is covered. Confirm the front suspension uses the coilover-style layout before ordering.

How much front lift does this 6100 shock give?

The adjustable ride height range is 0 to 3 inches with OE springs, depending on the application. The amount depends on the spring seat groove you select.

Does this shock have an eyelet mount at the bottom?

Yes. It has an OEM top mount and an eyelet bottom mount, so check the lower mount on your truck against the shock before buying.

How often should the upper mounts be inspected?

Check the upper mounts whenever the front shocks are serviced, and listen for knocks when turning or hitting bumps. Look for cracked rubber, loose fasteners and any movement at the mount. Worn mounts can change the adjusted height and cause the shock to bind.

Does a ride height adjustable shock need different springs?

Not necessarily. This shock is designed to work with OE springs across its adjustment range, so the spring seat groove sets the height. Replacing springs is a separate decision and should be based on the truck's load and how it sits after adjustment.
