Trail Gear Tube Clamps – 180127-KIT

Trail Gear

Shop Trail Gear Tubing Clamp on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Trail Gear 1.50 in tube clamp, part 180127-KIT
  • 1020 steel, clamping force up to 8,600 lb
  • Universal fit, sized by tube diameter
  • Sold individually

Description

Overview

The Trail Gear 1.50 in O.D. tube clamp, part number 180127-KIT, is a 1020 steel clamp for attaching suspension and steering brackets to tubing. It lets you mount a bracket without welding it to the tube, which helps when the bracket may need adjusting or removing.

This clamp is made from 1020 steel with a clamping force of up to 8,600 lb. It is sold individually and is universal fit with a size of 1.50 inches. Check the outside diameter of your tubing before ordering.

Key features

  • 1020 steel construction
  • Clamping force up to 8,600 lb
  • Designed for shock brackets on suspension links and steering brackets on steering rods
  • Suits aluminum suspension links and rods that cannot take welded steel brackets
  • 1.50 inch size

Sizing and tubing fit

Tube diameter is the first thing to confirm, because a clamp that is even slightly off will not seat evenly. Measure the outside diameter at the exact mounting spot, not just at the end of the tube. Round tubing is easier to measure with calipers; take readings at two angles to catch any out-of-round section.

Once the size is right, plan the bracket layout. Keep the clamp away from weld seams and bends, and make sure the bracket sits square so the load goes into the tube rather than the screws. Keep the zinc plated screws in good condition and inspect them each time the suspension is serviced.

  • Measure at the mounting spot
  • Avoid weld seams and bends
  • Recheck tightness after the first drives

Specifications

Brand Trail Gear
Part number 180127-KIT
UPC 70000621427
Size 1.50 in
Material 1020 steel
Clamping force Up to 8,600 lb
Sold as Individually

Vehicle fitment

It is universal fit, sized by tube diameter. Fitment depends on 1.50 inch tubing and the bracket you are mounting.

It is not tied to a particular vehicle. Confirm the tube diameter and bracket type before ordering.

What’s included

Check the package on arrival for the number of pieces and whether screws come with the clamp.

SKU: TGI180127-KIT Category:

Specification

Shipping weight 2.00 lbs
Package dimensions 7.50 × 7.50 × 3.50 in
brands

Questions & Answers

What size is Trail Gear 180127-KIT?

It is a 1.50 inch tube size, so match it to 1.50 inch tubing. It is a 1020 steel O.D. tube clamp sold individually, and it attaches brackets without welding.

Does the 180127-KIT clamp require welding?

Clamps used this way generally avoid welding, so the bracket can be adjusted or removed later. The attachment works by tightening the two halves around the tube, which keeps the bracket in place without heat.

What is the clamping force?

It is rated for a clamping force of up to 8,600 lb and is made from 1020 steel. Check the tube and bracket loads for your application before installing it on a steering or suspension part.

Is this clamp vehicle specific?

No vehicle is listed. The clamp is universal fit, so confirm the 1.50 inch tube diameter and the bracket type before ordering.

Can the clamp be reused after it has been removed?

Yes, the clamp can be removed and reinstalled, which is one reason to choose it over welding. Inspect the halves and screws for wear each time, and replace any that show damage before reinstalling.
