Overview
The Trail Gear 180129-KIT is an O.D. tube clamp for attaching brackets to tubing without welding. It is a universal fit part, so it is not tied to a specific year, make or model. Trail Gear designed the clamp for brackets that need to be adjusted or removed often, because the bracket clamps onto the tube instead of being welded to it.
A common use is attaching shock brackets to a suspension link, or steering brackets to steering rods or links. The clamp lets steel mounting brackets attach to aluminum suspension links and steering rods, which cannot be welded to directly with steel brackets. Trail Gear makes the clamp from 1020 steel.
Key features
- Clamps onto O.D. tubing so brackets can be added without welding
- Suits suspension link and steering rod brackets that need adjustment or frequent removal
- Lets steel brackets attach to aluminum suspension links and steering rods
- Manufactured from 1020 steel
- Rated clamping force of up to 8,600lbs
- Sized for 1.00 inch tubing
Frequent adjustment and removal
Brackets that get moved often put repeated stress on their fasteners and on the tube. A clamp that grips the tube without welding makes removal simple, but it also means the hardware must be checked more often. Inspect the clamp halves for cracks and the screws for stretch or thread damage whenever the bracket is removed.
Think about the bracket’s role before choosing the mounting spot. Shock brackets and steering brackets see different loads, so keep each clamp clear of sharp bends and weld seams. Clean the tubing before installation so the clamp grips evenly, and repeat the check after rough trail sessions.
- Check screws after each removal
- Look for cracks in the clamp halves
- Keep the clamp clear of weld seams
Specifications
| Brand | Trail Gear |
|---|---|
| Part number | 180129-KIT |
| UPC | 70000621425 |
| Material | 1020 steel |
| Clamping force | Up to 8,600lbs |
| Size | 1.00 Inches |
Vehicle fitment
It is universal fit, so it is not tied to a specific vehicle. Check that the 1.00 inch size suits your tubing and bracket layout before installing.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
This clamp is a non-welded way to attach a bracket to tubing, so it suits parts you may need to remove later. Make sure the clamp is tight and aligned on the tube before the suspension or steering is loaded.
What’s included
Contents are identified only by the 180129-KIT part number, so check the package for the exact pieces supplied.
