Overview
The Smittybilt XRC GEN3 9.5K Comp Series Winch with Synthetic Cable, part number S/B98695 (model 98695), is a 12-volt electric recovery winch with a 9500 lbs line pull rating. The Comp Series upgrade adds a synthetic rope and an aluminum hawse fairlead.
It has a 7.0 horsepower motor with a line speed 12% faster than the Gen2 and lower amp draw at load. The remote controller has a Load Indicator Warning System, a built-in flashlight and a 12 feet lead.
Key features
- 9500 lbs line pull rating
- Synthetic rope with a hawse fairlead
- 7.0 horsepower motor with a line speed 12% faster than the Gen2
- Ergonomic remote controller with a Load Indicator Warning System
- Remote with a built-in flashlight and two built-in magnets
- 12 feet remote lead
- 12-volt power post on the control box
- High-visibility clutch lever, and detachable body armor
- Lifetime mechanical warranty and 5-year electrical warranty
Synthetic rope care and remote use
Synthetic rope is lighter and easier to handle than steel cable, but it has its own care needs. Keep it off the ground when possible, avoid sharp edges and rock contact, and do not let it run over a hard surface under load. Heat and abrasion are the usual causes of early wear, so inspect the rope after each recovery for fuzzing, cuts or melted spots, and retire it when damage reaches the core.
The remote and control box deserve the same attention. Keep the remote in a dry place when not in use, and check the cord for cracks where it enters the housing. Test the controls before a trip so you know the winch responds in both directions. If you carry a recovery damper, keep it on the line near the hook for every pull, since it limits the chance of a snapback.
- Inspect rope after every recovery
- Use a tree trunk protector or strap for anchors
- Keep the fairlead free of grit
- Test the remote before each trip
Specifications
| Brand | Smittybilt |
|---|---|
| Part number | S/B98695 |
| Product type | Electric recovery winch |
| Series | XRC GEN3 9.5K Comp Series |
| Line pull rating | 9500 lbs |
| Line type | Synthetic rope |
| Fairlead | Hawse (aluminum) |
| Motor | 7.0 horsepower |
| Remote control | 12 Feet lead |
| Warranty | Lifetime mechanical, 5-year electrical |
| Fit type | Universal |
Vehicle fitment
It is a universal fit, so check the mounting pattern, your bumper or winch mount, and the electrical capacity of your vehicle before installing.
This winch is not vehicle-specific, and it needs a suitable winch mount or bumper. Confirm that the winch size, mounting pattern and your vehicle’s weight suit your setup before ordering.
Installation notes
Mount the winch to a bumper or winch plate rated for its load, and use grade-rated hardware tightened to the torque values for that hardware. Wire it with appropriately sized cables, protect them from heat and sharp edges, and fuse or breaker-protect the circuit. Disconnect the battery during work. Use gloves and a recovery damper when winching, keep bystanders clear, and never exceed the rated line pull. Inspect the synthetic rope regularly.
What’s included
A XRC GEN3 9.5K Comp Series winch with synthetic rope, an aluminum hawse fairlead and a remote controller with a 12 feet lead.
Not included: A winch mount or bumper, battery cables unless listed by the manufacturer, and recovery gear.
