Overview
The Smittybilt 4 inch drop aluminum ball mount in satin finish is a Class 4 hitch for trailers up to 8,000 lbs gross trailer weight, with an 800 lb tongue weight. The 4 inch drop suits trailers that sit only slightly below the receiver.
Smittybilt makes the mount from 6061 aluminum, hard anodized for weather resistance and finish retention. The mount is forged, which Smittybilt says gives superior strength for its light weight.
Key features
- 4 inch drop
- Class 4 rating
- Hard anodized 6061 aluminum
- Forged construction
- Satin finish
Before towing a loaded trailer
Shallow drops leave little clearance between the ball and the rear bumper, especially when the trailer’s tongue is pushed down at the coupler. Check clearance at full turn and under braking, because the trailer can pitch forward when the brakes are applied. A quick walk around the setup before each trip catches loose connections and worn parts early.
Aluminum resists weather well, but it can still show wear where the pin holes and drop bend under load. Look over the hitch after the first few trips with a new trailer, and watch for shiny rub marks or cracks near the receiver end. Replace parts that show wear rather than running them until they fail.
- Check bumper clearance at full turn
- Recheck the hitch after the first trips
- Look for rub marks near the receiver end
- Confirm the pin is seated before moving
Specifications
| Brand | Smittybilt |
|---|---|
| UPC | 631410111972 |
| Product type | Drop ball mount |
| Material | 6061 aluminum, hard anodized |
| Finish | Satin |
| Drop | 4 inch |
| Hitch class | Class 4 |
| Gross trailer weight | 8,000 lbs |
| Tongue weight | 800 lbs |
| Shank hole | 1 inch |
Vehicle fitment
No vehicle or model years are named for this mount. Check that your receiver matches the 2 inch by 2 inch size before buying.
Confirm the receiver size and weight rating against your vehicle and trailer before ordering.
Installation notes
Compare the height of the trailer coupler with the receiver before choosing a 4 inch drop, since the drop sets the ball height. Stay within the Class 4 limits of 8,000 lbs gross trailer weight and 800 lbs tongue weight.
