Revtek 3 Inch Rear Lift Kit – 432R

Revtek

Shop Toyota FJ Cruiser Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Revtek 3 inch rear lift for the 2010–2014 Toyota FJ Cruiser
  • Rear coil spring spacers with rear shocks included
  • Lift height range of 3 to 4.99 inches
  • Lifetime warranty and detailed instructions
  • Part number 432R

Description

Overview

The Revtek 432R is a 3 inch rear lift kit for the 2010–2014 Toyota FJ Cruiser. It uses rear coil spring spacers and includes rear shocks, so the rear is raised by 3 inches.

Revtek says each lift kit comes with detailed instructions, all the hardware needed and a lifetime warranty. The listed lift range is 3 to 4.99 inches.

Key features

  • Rear coil spring spacers for a 3 inch rear lift
  • Rear shocks included
  • Lift height range of 3 to 4.99 inches
  • Includes detailed instructions and all the hardware needed for installation.
  • Covered by a lifetime warranty.

Choosing a rear lift

A rear coil spring spacer lift raises the body by placing a spacer between the spring seat and the coil spring, which changes the resting height without changing the spring’s rate. On a truck or SUV that carries cargo or towing loads, the rear can sit higher than the front, so the lift is best judged loaded as well as empty. Spacers also change suspension travel, so the bump stops and the shock’s extended length should be checked for clearance.

Raising the rear changes the driveshaft angle, and worn rear shocks, bushings or bump stops are often replaced during the same job. Inspect the shock mounts, brake hoses and rear track bar for stretch or wear after the first few drives. Recheck the mounting hardware after the first trail runs and periodically afterward, since new fasteners can settle as the spring seats.

Specifications

Brand Revtek
Part number 432R
UPC 811323011983
Position Rear
Suspension type Spacer
Rear lift method Coil spring spacers
Lift height range 3 to 4.99 inches
Shocks Rear shocks included

Vehicle fitment

It fits the 2010–2014 Toyota FJ Cruiser.

Confirm fit for your vehicle’s year, model and trim before ordering, especially outside 2010–2014.

Installation notes

This is a rear-only lift, so the front height stays the same. The kit includes all the hardware needed. Check the alignment and the rear shock length after installation.

What’s included

The kit includes the rear coil spring spacers, rear shocks, the hardware needed for installation, and detailed instructions.

SKU: REV432R Category:

Specification

Shipping weight 18.00 lbs
Package dimensions 24.00 × 7.00 × 7.00 in
brands

Fitment

VehicleYearsTrims
Toyota FJ Cruiser2010–2014Base

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the Revtek 432R fit a 2012 FJ Cruiser?

Yes. The 432R fits the 2010–2014 Toyota FJ Cruiser, and a 2012 model falls within that range. Confirm fit for your vehicle's year, model and trim before ordering.

Are shocks included with the 432R?

Yes. Rear shocks are included with the kit. This is a rear-only kit, so the front suspension is not changed by it and the front shocks stay as they are.

What lift height does the 432R provide?

The lift height range for the 432R is 3 to 4.99 inches at the rear. The kit is a 3 inch rear lift, so the rear is raised by about 3 inches.

Should worn rear shocks be replaced with a lift?

Often yes. Shocks that are worn or too short for the new spring height can limit travel and wear faster, so inspect them before installing spacers. Check shock length against the lifted height before buying a replacement.
