Overview
The Rancho RS7264 is a front RS7000MT Series monotube shock for a 4 in. lift. It fits the 2000–2005 Ford Excursion and the 1999–2004 Ford F-250 and F-350 Super Duty. Its gas-charged monotube body uses ten-stage velocity-sensitive valving.
The damping is tuned for off-road obstacles. The shock includes a 14mm chrome rod, black natural rubber bushings and a protective boot.
Key features
- Front-position shock for the listed Excursion and Super Duty entries.
- Gas-charged monotube design aimed at heat dissipation.
- Ten-stage velocity-sensitive valving.
- 14mm chrome rod.
- Black natural rubber bushings.
- Protective boot included.
Front shock basics
A front shock works with the steering knuckle, control arms and springs to keep the tires in contact with the ground. Because the front end steers and carries engine weight, the shock sees side loads that rear units do not, so the bushings and mounting hardware take a lot of stress over time.
When replacing a front shock, inspect the upper and lower bushings and the bolts that secure them. Worn rubber can make the steering feel vague or cause a clunk over bumps. Check that the new unit sits at the same angle as the old one so the travel is not restricted at full compression.
- Inspect bushings at each tire rotation
- Look for cracked or flattened rubber
- Confirm the mounts match the old unit before installing
Specifications
| Brand | Rancho |
|---|---|
| Part number | RS7264 |
| UPC | 39703002431 |
| Shock series | RS7000MT Series |
| Position | Front |
| Design | Monotube, gas charged |
| Body diameter | 1.97 inch (50mm) |
| Rod | 14mm chrome |
| Valving | Ten-stage, velocity-sensitive |
| Bushings | Black natural rubber |
| Lift height | 4 in. lift |
| Finish | Brushed-zinc clear coat |
| Fitment type | Direct fit |
Vehicle fitment
Rancho’s entries for the RS7264 cover the 2000–2005 Ford Excursion (Eddie Bauer, Limited, XLS and XLT), the 1999–2004 Ford F-250 Super Duty (Harley-Davidson Edition, King Ranch, Lariat, XL and XLT), and the 1999–2004 Ford F-350 Super Duty with the same trim set.
Super Duty model years after 2004 are outside the F-250 and F-350 entries. Confirm your vehicle’s year, model and trim before ordering.
What’s included
A protective boot is part of the package.
Not included: Mounting hardware. Check the package contents against your installation before starting.
