Overview
The Pro Comp 89 Series Kore in 17×9 inches is a cast aluminum spoke wheel in flat black, part number PXA7089-7973, with a 5 on 5 bolt pattern. Pro Comp Alloy Wheels markets the 89 Series for trucks and SUVs that need a larger wheel with brake clearance, and this 9 inch wide version is one of its size options.
The wheel has a -6 offset and 4.75 backspacing. The negative offset places the mounting face behind the centerline, so the wheel sits farther out from the hub. The 83 center bore centers the wheel on the hub when it is mounted. Read the width, offset and backspacing together before deciding whether the wheel will clear your setup.
Key features
- Cast aluminum spoke design in flat black
- 17 inch diameter and 9 inch width
- 5 on 5 bolt pattern
- 83 center bore
- -6 offset with a 4.75 backspacing
- Part of the Pro Comp 89 Series
Backspacing and brake room
Backspacing is the distance from the mounting face to the back edge of the rim, and it sets how much room the inner lip has behind the brake caliper and suspension. A -6 offset pushes the wheel outward, which helps caliper room but can reduce room at the fender. Measuring both figures against the actual parts on the vehicle is more reliable than comparing numbers alone.
A wide 9-inch rim also changes how the tire fills the wheel well. Choose a tire width that suits this rim, and check the tire’s overall height so the speedometer and gearing stay close to what the vehicle expects. Trail use can pack debris behind the wheel, so look for rubbing marks on the inner fender after each outing.
- Test steering at full lock after mounting
- Check the brake caliper for clearance over bumps
- Measure fender clearance with the tire you plan to run
Specifications
| Brand | Pro Comp Alloy Wheels |
|---|---|
| Part number | PXA7089-7973 |
| Series | 89 Series Kore |
| Construction | Aluminum |
| Style | Spoke |
| Finish | Flat black |
| Diameter | 17 inches |
| Width | 9 inches |
| Bolt pattern | 5 on 5 |
| Center bore | 83 |
| Offset | -6 |
| Backspacing | 4.75 |
Vehicle fitment
Fitment depends on the hub and clearances. The 5 on 5 bolt pattern and 83 center bore define the hub match, and the -6 offset controls how far the wheel stands out. Compare those three figures with your vehicle’s hub and clearance measurements before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Check that the tire and the brake caliper clear the 9 inch rim at full steering lock. If you are switching from a wheel with a positive offset, the new position will change the way the tire rubs or clears the fender liner, so road-test the setup slowly after mounting.
What’s included
The 17×9 wheel is sold alone as part PXA7089-7973.
