Pro Comp 4 Inch Lift Kit with ES3000 Shocks – K5055B

Pro Comp Suspension

Shop Toyota Pickup Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • A 4-inch Stage 2 kit for the 1986–1995 Toyota 4Runner and Pickup
  • Steering knuckle spacers, front and rear crossmembers and front sway bar links
  • Bump stop extensions and upper control arm mount brackets
  • Rear block and U-bolt kit with ES3000 front and rear shocks

Description

Overview

The Pro Comp K5055B is a 4-inch Stage 2 spacer lift kit with ES3000 front and rear shocks for the 1986–1995 Toyota 4Runner and Toyota Pickup. Steering knuckle spacers and front and rear crossmembers raise the front, and a rear block and U-bolt kit lifts the back.

The Stage 2 version adds bump stop extensions and upper control arm mount brackets to the front package. Front sway bar links are included, and the rear lift uses lift blocks with U-bolts.

Key features

  • 4-inch lift height, Stage 2
  • Steering knuckle spacers
  • Front and rear crossmembers
  • Front sway bar links
  • Bump stop extensions
  • Upper control arm mount brackets and a block and U-bolt rear lift

Choosing the right setup

A lift kit changes more than ride height. Spacers and crossmembers move the steering knuckles and control arms, so the front geometry shifts once the truck is raised. Think about how the lift will work with the tires, bumpers and driveline you plan to run. A kit that raises the front and rear together tends to keep the stance more even, which helps with alignment and with how the truck sits on the road.

Compare stage levels before buying. Extra brackets and bump stop extensions add parts that work with the arm geometry, while a simpler package leaves some items for later. Shock load also rises with a taller setup, so check the shock mounts during each inspection. Budget for an alignment as part of the install, and recheck it after the first few drives on rough roads.

Specifications

Brand Pro Comp Suspension
Part number K5055B
UPC 614901207200
Lift height 4 inch (lift height range 3 to 4.99 inches)
Lift kit stage Stage 2
Suspension type Spacer
Front lift Steering knuckle spacers
Rear lift Lift blocks and U-bolts
Front shocks ES3000
Rear shocks ES3000

Vehicle fitment

It fits the 1986–1995 Toyota 4Runner in the DLX and SR5 versions, and the 1986–1995 Toyota Pickup in the Base, Base Turbo, DLX, SR5 and SR5 Turbo versions.

Coverage stops at the 1995 model year, so the later 4Runner and Pickup generations are not included. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Knuckle spacers and the upper control arm brackets change the front geometry, so have the alignment checked and the driveline angles measured after the install.

What’s included

The kit includes steering knuckle spacers, front and rear crossmembers, front sway bar links, bump stop extensions, upper control arm mount brackets, the rear block and U-bolt kit, and ES3000 front and rear shocks.

SKU: EXPK5055B Category:

Specification

Shipping weight 116.60 lbs
Package dimensions 0.00 × 0.00 × 0.00 in
brands

Fitment

VehicleYearsTrims
Toyota 4Runner1986–1995DLX, SR5
Toyota Pickup1986–1995Base, Base Turbo, DLX, SR5, SR5 Turbo

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the K5055B fit a 1990 Toyota 4Runner?

Yes. It fits the 1986 through 1995 Toyota 4Runner in the DLX and SR5 versions, so a 1990 model is inside that range. Confirm the trim on your truck before ordering.

Is the K5055B a Stage 2 kit?

Yes. The product name and the spec table both list it as a 4-inch Stage 2 kit, which adds bump stop extensions and upper control arm mount brackets to the front package.

Does it include shocks?

Yes. The kit includes ES3000 front and rear shocks, as named in the product name and listed in the specifications table.

How can I tell when the shocks on a lift kit need replacing?

Look for fluid leaks on the shock body, a bouncy ride after rough driving, or uneven tire wear that follows the damper. Check the mounting hardware too, since a taller setup puts more load on the shock ends. Replace shocks in pairs on the same axle so the truck handles evenly.
