Overview
The Pro Comp 2-inch Lift Kit with PRO-VST Coilovers and Shocks, part number EXPK5100BXU (kit K5100BXU), is a suspension lift for 2007 to 2021 Toyota Tundra trucks. It fits the Tundra across its Base, Limited, Platinum, SR5, SR and Trail versions, with a 35-inch tire size.
The specifications list a 2-inch suspension lift with a lift height range of 0 to 3.5 inches. PRO-VST shocks are listed at both the front and the rear, and they are included with the kit. The kit uses no rear lift component, so the rear is not raised by a separate block or spacer.
The Explorer Pro coilover system replaces the factory springs and shocks with PRO-VST coilovers. The 2-inch PRO-VST coilovers and shocks are built for highway ride quality and off-road performance.
The kit is intended for 17-inch wheels with 35-inch tires. Its vehicle-specific tuning corrects suspension geometry for the larger wheels and tires. The Pro Series Upper Control Arm upgrade is a separate part with high-angle ball joints, not included in this kit.
Key features
- 2-inch suspension lift
- PRO-VST coilovers and shocks included at the front and rear
- Designed for 35-inch tires with 17-inch wheels
- Vehicle-specific tuning for the Tundra
- Direct fit for the listed Tundra models
Coilover ride and alignment
Coilovers replace both the spring and the shock as one unit, so the ride height and damping are set together. On the highway this tends to give a firmer, more controlled ride than mismatched parts. Off road, the extra travel helps keep tires in contact with uneven ground when the truck is loaded.
Because the front geometry changes with a coilover system, alignment matters more than it would after a simple shock swap. Larger tires add weight and change the rolling radius, which also affects steering feel. Inspect the top mounts and the lower control arm bushings during regular service, and watch for uneven tire wear across the front.
- Recheck alignment after any change in tire size
- Look for play at the coilover mounts after rough trail use
- Inspect the boots and bushings for cracks at each oil change
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | EXPK5100BXU |
| Kit code | K5100BXU |
| Suspension type | Lift kit |
| Lift height | 2 inches; range 0 to 3.5 inches |
| Tire size | 35 inches |
| Shocks included | Yes |
| Front shocks | PRO-VST |
| Rear shocks | PRO-VST |
| Rear lift component | None |
| Fit type | Direct fit |
Vehicle fitment
The kit fits the 2007 to 2021 Toyota Tundra, in the 1794 Edition, Base, Limited, Nightshade, Platinum, SR, SR5 and Trail versions.
The list does not include the 2022 and newer Tundra. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Replacing the factory springs and shocks with coilovers changes the ride height and the front geometry, so have the alignment checked after installation.
What’s included
The 2-inch lift kit with front and rear PRO-VST coilovers and shocks.
