Overview
The Pro Comp K4085 is a 2-inch stage 1 coil spring spacer lift with ES3000 front and rear shocks. The front is raised with coil spring spacers, and there is no rear lift.
No steering correction is needed with this kit. Shock boots are not included. It is designed for wheels 15 inches or larger, with a maximum tire size of 33 x 12.50.
Key features
- 2-inch stage 1 lift
- Front coil spring spacers
- No rear lift
- ES3000 front and rear shocks
- Steering correction not needed
- Wheel size 15 inches or larger
Before you buy
Coil spring spacers lift the front by keeping the stock coil springs and adding a spacer above them, so the spring rate stays close to stock. The front ends up higher than the rear, which changes caster and pinion angle. Expect to check alignment and driveline angles after installation and to recheck the spacer hardware after the first drives.
When choosing a spacer lift, think about how the vehicle will be used. Heavier loads or larger tires put more strain on the stock springs, and a front-only lift can make the rear look low. Track bar or control arm work is often done at the same time to restore geometry, so budget for those parts if the alignment cannot be brought back into range.
- Look over the shock mounts when the spacers go in
- Replace worn bushings before setting the alignment
- Confirm the tire and wheel setup clears the front fenders at full turn
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | K4085 |
| UPC | 614901125269 |
| Lift | 2 inches, stage 1 |
| Suspension type | Coil spring kit |
| Front lift | Coil spring spacers |
| Rear lift | None |
| Steering correction | Not needed |
| Front shocks | ES3000 |
| Rear shocks | ES3000 |
| Shock boots | Not included |
| Max tire size | 33 x 12.50 |
| Wheel size range | 15 inches or larger |
Vehicle fitment
Confirm fit for your vehicle’s year, model and trim before ordering. Check the front spring layout on your truck against the kit before installing.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Coil spring spacers raise the front without changing the spring itself, so the alignment should be checked after installation and the front ride height compared with the rear.
What’s included
The kit includes front coil spring spacers and ES3000 front and rear shocks. Shock boots are not included.
