Overview
The Omix-Ada 12004.04 is a passenger side, front right replacement steel fender for the Jeep CJ3 and Willys CJ-3. It is built to original Omix-Ada specifications and is primed for rust prevention.
It fits the 1959–1960 Jeep CJ3 (Base) and the 1949–1958 Jeep Willys CJ-3, which makes it an early-model body panel rather than a later Jeep fender.
Key features
- Steel body panel built to original Omix-Ada specifications
- Passenger side, front right position
- Primed for rust prevention; the finish paint is applied by the owner
- Direct fit for the 1949–1958 Willys CJ-3 and 1959–1960 CJ3
Fitting an early body panel
Early CJ-era body panels were built with simpler bolt-on mounts and fewer adjustment points, so the fit depends heavily on the condition of the surrounding metal. Before setting the new fender, check the body mount holes, the fender edges and the hinge area for bent or fatigued metal. Small distortions can make the panel sit high or low, and that is much easier to correct before paint.
Hinge bolts and their threads deserve attention. Old hardware can be stretched or rusted even when the fender looks sound, and worn threads can keep the panel from lining up. Clean the threads, replace fasteners that are damaged, and set the panel loosely first so the gaps can be adjusted evenly.
Keep the primed panel indoors and handle it carefully. Primer protects the surface, but scratches and dents expose bare metal to rust before topcoat goes on.
- Check body mount holes for distortion
- Clean or replace worn hinge bolts
- Set the panel loosely before final tightening
Specifications
| Brand | Omix-Ada |
|---|---|
| Part number | 12004.04 |
| UPC | 804314147068 |
| Material | Steel |
| Finish | Primed for rust prevention |
| Side | Passenger side |
| Position | Front right |
| Fit type | Direct fit |
| Warranty | Covered by a limited five year warranty |
Vehicle fitment
It fits the 1959–1960 Jeep CJ3 (Base) and the 1949–1958 Jeep Willys CJ-3.
The list does not include later Jeep body styles such as the Wrangler or Cherokee, so a fender for those vehicles is a different part. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Test-fit the panel against the hinge and inner fender locations before painting, so any adjustment is made while the panel is still bare.
What’s included
One passenger side, front right steel fender panel. Check the package contents against your installation before starting.
Not included: paint and any mounting hardware the vehicle requires.
