Omix-ADA Dana 44 Aluminum Crush Sleeve – 16512.62

Omix-Ada

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Collapsible Dana 44 aluminum pinion spacer, part 16512.62
  • Rear position for the Dana 44
  • Fits 1996-1998 Grand Cherokee ZJ
  • Direct OE replacement from Omix-ADA

Description

Overview

The Omix-ADA 16512.62 is an aluminum Dana 44 crush sleeve, also known as a collapsible pinion spacer. It is designed for the rear position of the Dana 44 axle and is a direct OE replacement for the 1996-1998 Jeep Grand Cherokee (ZJ). The sleeve sets pinion bearing preload during assembly.

It is built to original specifications and comes with a limited five year warranty. Confirm the pinion position on your axle before ordering, since the sleeve is sold with both rear and front axle locations.

Key features

  • Aluminum Dana 44 crush sleeve
  • Collapsible pinion spacer design
  • Direct OE replacement built to original specifications
  • Limited five year warranty.

Aluminum versus steel spacers

Crush sleeves come in aluminum and steel, and each is designed to deform to a set preload during assembly. Aluminum is softer, so it deforms at a lower load than steel, which suits a standard street or trail gear set. Steel holds its shape under heavier loads, so it is more common in demanding setups.

Whichever material is used, the spacer should be fitted fresh whenever the pinion is removed. Check the pinion bearing faces and the carrier bore for damage before setting preload, since a damaged surface can change the reading even with a new sleeve. Keep the old sleeve with the old parts so it is not mixed into a new build.

  • Use a new sleeve every time the pinion is set
  • Clean the bearing faces before setting preload
  • Match the sleeve to the pinion position on your axle

Specifications

Brand Omix-Ada
Part number 16512.62
UPC 804314030209
Part type Collapsible pinion spacer, aluminum
Axle type Dana 44
Position Rear
Axle location (listed) Front
Warranty Limited five year warranty.

Vehicle fitment

It fits the 1996-1998 Jeep Grand Cherokee (ZJ) in the 5.9 Limited, Laredo, Limited, Orvis and TSi versions. It is a direct fit for those models.

The ZJ years covered are 1996 to 1998, so 1993-1995 ZJ and the WJ are not covered. Confirm fit for your vehicle’s year, model and trim before ordering.

Installation notes

Because the spacer is collapsible, the pinion nut is tightened to the set preload and the bearing preload checked as the sleeve is crushed. Confirm the axle position before fitting, since the catalog shows both rear and front locations.

What’s included

One aluminum Dana 44 crush sleeve.

SKU: OAI16512.62 Category:

Specification

Shipping weight 0.40 lbs
Package dimensions 4.00 × 3.00 × 2.50 in
brands

Fitment

VehicleYearsTrims
Jeep Grand Cherokee (ZJ)1996–19985.9 Limited, Laredo, Limited, Orvis, TSi

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the Omix-ADA 16512.62 fit a 1997 Jeep Grand Cherokee ZJ?

Yes. The sleeve fits the 1996-1998 Grand Cherokee (ZJ), so a 1997 ZJ is within the covered years. It is a direct fit for the 5.9 Limited, Laredo, Limited, Orvis and TSi versions.

Is the 16512.62 made from aluminum?

Yes. It is an aluminum Dana 44 crush sleeve. It is a collapsible pinion spacer rather than a fixed shim.

Does the warranty cover this sleeve?

The 16512.62 carries a limited five year warranty. Keep your purchase record in case you need to make a claim.

Can I reuse an aluminum crush sleeve?

Usually not. A crush sleeve deforms once it is set to preload, so it cannot be relied on to hold the same setting a second time. Install a new sleeve each time the pinion is removed and reset.
