Overview
The Method Race Wheels MR315 17×8.5 in a Machined finish is part MRWMR31578588300, a 17-inch aluminum wheel with an 8 on 180 bolt pattern and a 131 center bore. The windowed design is marked Universal Fit, so it is not tied to a single named vehicle.
Method Race Wheels designed the MR315 for off-road use, with finite element analysis and field testing used during development. The design aims for lower weight and higher strength. Anyone considering an 8 on 180 wheel should check the center bore, offset and backspacing against their own hub first.
Key features
- 17-inch diameter with an 8.5-inch width
- Windowed style with a machined finish
- Aluminum construction
- 8 on 180 bolt pattern
- Center bore of 131
- Offset 0 and backspacing 4.75
Caring for a machined finish
A machined finish shows fine scratches more readily than a painted face, and the clear coat over it is the main protection against oxidation. Clean with a soft cloth and a non-abrasive wheel cleaner, and avoid stiff brushes that can scuff the surface.
Curb contact is the most common source of damage on a windowed design, because the spokes sit close to the edge. Check the inner lip and the window edges after each trip, and touch up small chips quickly to keep moisture from reaching the aluminum underneath.
Torque the lug nuts after the first few drives and again after any tire service. Aluminum can settle slightly against the hub, so a short retorque check helps keep clamping force steady over time.
Specifications
| Brand | Method Race Wheels |
|---|---|
| Part number | MRWMR31578588300 |
| Series | MR315 |
| Diameter | 17 Inches |
| Width | 8.5 Inches |
| Bolt pattern | 8 on 180 |
| Center bore | 131 |
| Offset | 0 |
| Backspacing | 4.75 |
| Style | Windowed |
| Finish | Machined |
| Construction | Aluminum |
| Fitment | Universal Fit |
Vehicle fitment
No make, model or year is attached to this Universal Fit wheel, so it is not confirmed for any particular vehicle.
The 8 on 180 pattern and 131 center bore have to match your hub, and the offset and backspacing affect clearance. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Measure your hub’s pilot diameter against the 131 center bore before mounting. If the hub is smaller than the bore, use a hub-centric ring to center the wheel.
What’s included
Only the wheel is covered here. Tires, lug nuts and center caps are not addressed, so check what else you need before ordering.
