Method Race Wheels 309 Grid, 17x8.5 with 8 on 6.5 Bolt Pattern – Titanium / Black – MR30978580800

Method Race Wheels

Shop Method Race Wheels 17x8.5 8x6.5 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Method Race Wheels 309 Grid, 17×8.5 aluminum off-road wheel, part number MRWMR30978580800
  • 8 on 6.5 bolt pattern with 131 center bore
  • Offset 0 and backspacing 4.75
  • Mesh style with a gray finish; Titanium / Black appears in the product name
  • No vehicle list is provided, so confirm bolt pattern and center bore against your hub

Description

Overview

The Method Race Wheels 309 Grid is a 17×8.5 aluminum off-road wheel with an 8 on 6.5 bolt pattern and part number MRWMR30978580800. It has a mesh face, a gray finish in its specifications and a Titanium / Black name, so it suits builds that need an open-faced wheel for an 8 on 6.5 hub.

Method Race Wheels builds the 309 Grid for off-road racing use. Each design is run through finite element analysis and field testing, with the aim of reducing weight while increasing strength. An offset of 0 places the mounting face at the wheel centerline, and the 4.75 backspacing sets how far the back of the wheel sits behind the mounting face, so both figures affect brake and suspension clearance.

Key features

  • 17-inch diameter and 8.5-inch width
  • Aluminum construction with a mesh style face
  • 8 on 6.5 bolt pattern and 131 center bore
  • Offset 0 and backspacing 4.75
  • Gray finish in the specifications, with Titanium / Black in the product name
  • Part of the MR309 Grid series
  • Method says each design was checked through finite element analysis and field tests

Open-face wheels and brake room

Open mesh faces let air reach the brake assembly, which many off-road drivers value after long descents where brakes heat up. The face style does not change the wheel’s load rating or how it bolts to the hub, so the hub match still comes first. Check the spacing between the inner barrel and caliper, because mesh designs can look like they clear more than they do once the tire is on.

Tire choice affects this wheel too. A taller or wider tire changes overhang and rubbing risk, so a test fit with the tire mounted is more reliable than measurement alone. Wheel bearings, ball joints and the brake rotor are often checked when a wheel is swapped, since a change in offset moves load across those parts.

Specifications

Brand Method Race Wheels
Part number MRWMR30978580800
Series MR309 Grid
Wheel diameter 17 inches
Wheel width 8.5 inches
Bolt pattern 8 on 6.5
Center bore 131
Offset 0
Backspacing 4.75
Style Mesh
Finish Gray
Construction Aluminum
Fitment label Universal Fit (manufacturer data)

Vehicle fitment

No vehicle year, make, model or trim is attached to this wheel. It carries a Universal Fit label, but a wheel only works on a hub that matches its bolt pattern, center bore, offset and backspacing, so the label alone does not confirm a vehicle. Confirm fit for your vehicle’s year, model and trim before ordering.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Choose a lug seat style that matches your lug nuts. Measure offset and backspacing against your brake calipers and fender clearance before mounting. Overall clearance also changes with tire size, so confirm the tire fits the 8.5-inch width.

What’s included

Only the wheel itself is described: one 17×8.5 Method 309 Grid wheel, with no tires or hardware named.

Not included: Tires, lug nuts and center caps are not part of this package.

SKU: MRWMR30978580800 Categories: ,

Questions & Answers

What bolt pattern and center bore does the Method 309 Grid 17x8.5 use?

It uses an 8 on 6.5 bolt pattern with a 131 center bore. Both dimensions have to match your hub. The offset of 0 and backspacing of 4.75 should also be checked against your vehicle's brake and suspension clearance before you order.

Will this wheel fit my vehicle?

No vehicle year, make, model or trim is given for this wheel. It carries a Universal Fit label, but fit depends on bolt pattern, center bore and offset, so compare those figures with your vehicle's manufacturer specifications.

What material and finish does this wheel have?

It is aluminum with a mesh style face and a gray finish. The product name also gives a Titanium / Black colorway, so confirm the exact color with Method Race Wheels if the finish matters to your build.

Are lug nuts or tires included with this wheel?

This is a single wheel only. Lug nuts, center caps and tires are not included, so source those separately and match the lug seat style to your nuts.

How do I know if the offset is right for my build?

Compare offset and backspacing with your hub face, brake caliper and fender clearance. A test fit with the tire mounted shows whether the wheel rubs or sits too far in or out, which is the most reliable check before driving.
