Hotchkis Sport Suspension Trailing Arm – 1305

Hotchkis Sport Suspension

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Double adjustable upper trailing arm for GM A/G-body and 2000–2006 full-size GM models
  • Swivel-Max bushings for non-binding articulation
  • Adjustable pinion angle to reduce vibration
  • Gloss black powder coat with clear anodized finish
  • Part number HOT1305

Description

Overview

Part number HOT1305 is a double adjustable upper trailing arm for the rear suspension. It fits 2000–2006 full-size GM trucks and SUVs, including the Tahoe, Suburban, Yukon, Escalade and Hummer H2. Confirm the fit for your vehicle before ordering.

The arm adjusts pinion angle, which can reduce vibration and improve traction. Its Swivel-Max bushings allow non-binding movement through suspension travel. The arm is finished in gloss black powder coat with clear anodizing.

Key features

  • Double adjustable design for easy pinion angle adjustment.
  • Swivel-Max bushings for non-binding articulation through suspension travel.
  • Gloss black powder coat with clear anodized finish.
  • Designed for high horsepower use.
  • Upper trailing arm position.

Setting pinion angle and checking bushings

A trailing arm is the part that keeps the axle located under acceleration and braking. Adjusting it changes the pinion angle, which is the angle between the driveshaft and the rear axle. When that angle is off, vibration and wear show up in the driveline and the u-joints, so measure before and after any change.

Bushings deserve the same attention. Inspect the rubber or urethane for cracks, separation and play, and check the bolts for proper torque after the first few drives. Replace worn bushings in the same job, since a loose arm changes the pinion angle and undoes the adjustment.

  • Measure pinion angle before and after adjusting
  • Check the Swivel-Max bushings for play
  • Re-check bolts after the first few drives
  • Inspect u-joints if vibration returns

Specifications

Brand Hotchkis Sport Suspension
Part number HOT1305
Type Double adjustable upper trailing arm
Bushings Swivel-Max
Finish Gloss black powder coat and clear anodizing

Vehicle fitment

It fits 2000–2006 Cadillac Escalade, Chevrolet Suburban 1500, Chevrolet Tahoe, GMC Yukon, GMC Yukon XL 1500 and Hummer H2 models across their trim levels. Confirm your year and model before ordering.

Confirm your vehicle’s year, model and trim before ordering.

What’s included

One upper trailing arm. Check the installation hardware against your setup before fitting.

Fitment

VehicleYearsTrims
Cadillac Escalade2000, 2002Base
Chevrolet Suburban 15002000, 2006Base, LS, LT, LTZ, Z71
Chevrolet Tahoe2000, 2003, 2006Base, LS, LT, Z71
GMC Yukon2000, 2006SL, SLE, SLT
GMC Yukon XL 15002006SL, SLE, SLT
Hummer H22003Base

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the HOT1305 fit a Monte Carlo or El Camino?

No. It fits 2000 to 2006 full-size GM trucks and SUVs. Monte Carlo and El Camino are not included, so confirm your vehicle before ordering.

Does this arm fit a 2007 Tahoe?

No. The fitment listed covers the 2000 and 2002 Cadillac Escalade, the 2000, 2003 and 2006 Chevrolet models, and the 2000 and 2006 GMC Yukon. A 2007 Tahoe is not on the list, so check the year before choosing.

What is a Swivel-Max bushing?

A Swivel-Max bushing allows non-binding articulation through suspension travel. That lets the arm move freely as the axle cycles, which supports traction and rear suspension efficiency.

Can the pinion angle be adjusted?

Yes. The arm is double adjustable, which makes it straightforward to set the pinion angle. A correct pinion angle can reduce driveline vibration.

How often should trailing arm bushings be inspected?

Check them during routine service and after heavy use, such as hard launches, off-road work or towing. Look for cracks, separation, looseness and changes in the axle position. Worn bushings should be replaced before they affect the pinion angle.
