California Supertrucks 2.0 Reservoir Shock – CSR-6521

California Super Trucks

Shop GMC Sierra 3500 HD Shock Absorbers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front 2.0 reservoir shock, part number CSR-6521, gas charged
  • Fits 2011–2018 Chevrolet Silverado 2500 HD and 3500 HD trucks
  • Fits 2011–2018 GMC Sierra 2500 HD and 3500 HD trucks
  • Bushing mounts instead of heim joints, all required hardware included

Description

Overview

The California Super Trucks CSR-6521 is a front 2.0 reservoir shock absorber for lifted 2011–2018 Chevrolet Silverado 2500 HD and 3500 HD and GMC Sierra 2500 HD and 3500 HD trucks. It is gas charged and designed for a 6 to 8 in. lift range.

Reservoir shocks keep the gas charge in an external canister connected to the body by a hose. This shock is built in the U.S.A. and uses bushings rather than heim joints.

Key features

  • Front-position 2.0 reservoir design
  • Gas charged
  • Bushing mounts instead of heim joints
  • Built in the U.S.A.
  • Designed for a 6 to 8 in. lift range

Why reservoir shocks suit heavy trucks

Reservoir shocks separate the gas charge from the damper body, which lets the shock keep damping steadier under heavy loads and repeated work. On a heavy-duty truck, that separation helps control body motion when towing or carrying a load. The external canister also makes the design more forgiving under sustained use, which suits trucks that spend long days working.

When comparing front reservoir shocks, match the lift range to your suspension and confirm the mount style and hardware before ordering. Check the hose and canister for rubbing against the frame, the tire or the steering components. Front end parts such as ball joints and steering linkage are often inspected during a shock change, since they affect how the truck handles.

Specifications

Brand California Super Trucks
Part number CSR-6521
UPC 70000587441
Position Front
Type 2.0 reservoir shock
Hydraulic / gas charged Gas charged
Lift range 6 to 8 in.
Mounting Bushings, no heim joints
Hardware All required hardware included
Origin Built in the U.S.A.

Vehicle fitment

The list covers 2011–2018 Chevrolet Silverado 2500 HD and 3500 HD trucks in the High Country, LT, LTZ and WT trims, and GMC Sierra 2500 HD and 3500 HD trucks in the Base, Denali, SLE, SLT and WT trims.

Earlier and non-HD Silverado and Sierra models are not in this list. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Because the shock uses bushings, the manufacturer-installed heim joints do not have to be pressed out. Support the truck securely before removing the factory shock.

What’s included

All required hardware is included with the shock.

SKU: CSTCSR-6521 Category:

Specification

Shipping weight 16.00 lbs
Package dimensions 28.00 × 8.00 × 8.00 in
brands

Fitment

VehicleYearsTrims
Chevrolet Silverado 2500 HD2011–2018High Country, LT, LTZ, WT
Chevrolet Silverado 3500 HD2011–2018High Country, LT, LTZ, WT
GMC Sierra 2500 HD2011–2018Base, Denali, SLE, SLT, WT
GMC Sierra 3500 HD2011–2018Base, Denali, SLE, SLT, WT

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the CSR-6521 fit a 2011 to 2018 Silverado 2500 HD?

Yes. Chevrolet Silverado 2500 HD trucks from 2011 to 2018 are covered in the High Country, LT, LTZ and WT trims. A GMC Sierra 2500 HD is covered too, so confirm your trim before ordering.

Does this shock need the factory heim joints pressed out?

No. This shock uses bushings instead of heim joints, so the factory heim joints do not need to be pressed out during installation.

What lift range is the CSR-6521 designed for?

The only lift range for this shock is 6 to 8 in., so confirm it matches your planned suspension height before ordering.

How do I know if a reservoir shock needs replacing?

Look for oil leaks on the body or the hose, a reservoir that has come loose, and a truck that keeps bouncing after bumps. Worn bushings also show up as clunks at the mounts.
