Overview
The California Super Trucks CSTCSS-D16-3 is a 1-inch rear lift kit for the Ram 1500. It fits 2009 and 2010 models, 2011 through 2017 models and 2019 models. It lifts the rear of the truck only, so the front stays at its factory height.
The kit is a 1-inch rear lift with a lift height range of 0 to 3.5 inches. Check the parts in the box against part number CSTCSS-D16-3 before starting the installation.
Key features
- 1-inch rear lift for Ram 1500 pickups
- Rear-only design, with no change to front height
- Lift height range of 0 to 3.5 inches
- Direct fit for 2009–2010, 2011–2017 and 2019 Ram 1500 models
Rear-only lift considerations
A rear-only lift changes how the back of the truck sits relative to the front, so the stance can look uneven. Many owners add a front lift of similar height to level things out, but that is a separate decision with its own parts and alignment work. Check the rear driveline angle after the lift is in, since the pinion moves with the axle and a steep angle can cause vibration at highway speed.
Before choosing a rear lift, consider the load the truck carries. Towing and heavy bed loads push the rear down, which affects both height and handling. Brake line length should also be checked, because the rear axle travels further from the frame. Brake hoses, bump stops and rear shock mounts are often inspected or replaced at the same time.
Specifications
| Brand | California Super Trucks |
|---|---|
| Part number | CSTCSS-D16-3 |
| Lift type | Rear lift |
| Rear lift height | 1 inch |
| Lift height range | 0 to 3.5 inches |
| Fitment type | Direct fit |
Vehicle fitment
Coverage includes 2009 and 2010 Ram 1500 models, 2011 through 2017 and 2019 models, across Laramie, SLT, Big Horn, Rebel, Tradesman and Sport trims.
The 2018 Ram 1500 is not among the covered years, so confirm fit for your vehicle’s year, model and trim before ordering.
Installation notes
A rear-only lift changes the rear suspension height and the rear driveline angle. After installation, check the driveshaft angles and the length of the rear brake lines, and recheck the alignment if the front is also changed.
What’s included
Check the packing list in the box against part number CSTCSS-D16-3 before installing.
