Overview
The Bilstein 24-184847 is a 4600 Series front shock absorber for Dodge Ram trucks. It is a gas-charged monotube shock with a yellow finish, 2 in body diameter, boots included and no external reservoir. Its fitment is direct with 0 in lift/drop.
In this monotube gas-charged design, heat moves from the oil to the outer shock body, where it dissipates. A dividing piston lets the oil expand as heat builds, which helps prevent foaming and thinning. The tube is extruded to tight peak-to-valley tolerances, and the piston head allows compression and rebound damping to be tuned independently. Bilstein presents the layout as a way to keep ride comfort and durability high over the life of the shock.
Key features
- Fits the 1994-2001 Dodge Ram 1500 across its listed trims
- Fits the 1994-2002 Dodge Ram 2500 and 3500 in Base trim
- Gas-charged monotube body with a dividing piston
- Extruded tube with consistent wall thickness
- Independent compression and rebound tuning
- Boots included, yellow finish, 2 in body diameter
- Uses fewer parts than conventional twin-tube designs
Before you replace a shock
Front shocks control how quickly the suspension compresses and rebounds, which keeps the tires in contact with the road over bumps. On older Ram trucks, worn front shocks often show up as nose dive when braking and a loose feel on uneven pavement.
When replacing a front shock, check the upper and lower mounts for cracking or wear, since worn bushings can make a new shock feel less controlled. Gas-charged bodies are pressurized, so keep heat away from the tube and avoid cutting or puncturing it during removal.
Before installing, compare the mounting eye positions with the removed unit and confirm the trim and year on your truck. Front suspension parts are often inspected together, so look at the springs and sway bar links as well.
- Inspect upper and lower mounts before installation
- Check sway bar links for play
- Keep heat sources away from the gas-charged body
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-184847 |
| UPC | 651860417936 |
| Shock series | 4600 Series |
| Position | Front |
| Type | Monotube |
| Hydraulic / gas charged | Gas charged |
| Body diameter | 2 in |
| Reservoir | No |
| Boots included | Yes |
| Finish | Yellow |
| Lift / drop | 0 in |
| Fitment type | Direct fit |
Vehicle fitment
The Dodge Ram 1500 fits 1994-2001 in Base, LT, Laramie, ST, Sport and WS trims. The Ram 2500 and 3500 fit 1994-2002 in Base trim.
Ram 1500 model years after 2001 and Ram 2500 or 3500 model years after 2002 are outside this list. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Gas-charged bodies are pressurized, so keep this front shock away from heat and do not puncture or open it. Check that the front mounting eyes line up with the removed unit before tightening the hardware.
What’s included
One 4600 Series front shock absorber with boots included.
