Artec Tube Tabs – TB1013

Artec Industries

Shop Artec Industries Gussets Tabs on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Artec Industries TB1013 misc. mounting tab, sold as a pair, designed for 1.75-inch tubing
  • Cut from 1/4-inch steel with a 1/2-inch bolt hole
  • Hole center set 1.25 inch from the top of the tube
  • Universal fit, with no year, make or model tied to it

Description

Overview

The Artec Industries TB1013 is a pair of misc. mounting tabs, the tube shock tabs used to fabricate mounts on round tubing. Each tab is cut from 1/4-inch steel and is designed for 1.75-inch tubing, with a 1/2-inch bolt hole whose center sits 1.25 inch from the top of the tube.

The tabs are a general fabrication part rather than a bracket made for one vehicle, so fit depends on your build and your tube size.

Key features

  • Cut from 1/4-inch thick steel
  • 1/2-inch bolt hole in each tab
  • Hole center set 1.25 inch from the top of the tube
  • Designed for 1.75-inch (1-3/4 inch) tubing
  • Two pieces, sold as a pair

Fabricating on round tubing

Tube shock tabs give a flat welding surface on round tubing, so a bracket can be attached without clamping anything around the tube. The tab is welded to the tube where the mount is needed, and the bolt hole then takes the fastener for a shock, link or accessory. Good results depend on clean metal, square placement and a weld that penetrates both the tab and the tube wall.

Before cutting or welding, mark the hole center on the tab and check it against the arm or bracket it must line up with. Tube wall thickness and nearby gussets change how much heat the joint can take, so test-fit the tab in place before tacking it. Grind mill scale off the contact area and let the weld cool slowly to limit distortion.

  • Check tube diameter before cutting
  • Clean the weld area to bare metal
  • Test-fit the tab before final welding
  • Re-check bolt torque after the first trail runs

Specifications

Brand Artec Industries
Part number TB1013
UPC 816791023629
Type Misc. mounting tab
Material Steel
Thickness 1/4 inch
Bolt hole 1/2 inch
Hole center from top of tube 1.25 inch
Tube diameter 1-3/4 inch (1.75 inch)
Quantity Two pieces (sold as a pair)

Vehicle fitment

The tabs are universal fit and are not tied to a specific year, make or model. Fit depends on your tube diameter, since the tabs are designed for 1.75-inch tubing.

Confirm your vehicle’s year, model and trim before ordering.

What’s included

Two tabs, sold as a pair. Welding rod, bolts and other hardware are not included.

SKU: A/ITB1013 Category:

Specification

Shipping weight 0.80 lbs
Package dimensions 6.00 × 6.00 × 6.00 in
brands

Questions & Answers

Does the Artec TB1013 fit a specific vehicle?

The TB1013 is universal fit and is not tied to one vehicle. Because the tabs are designed for 1.75-inch tubing, confirm the tube diameter in your build before ordering.

What tube size is the Artec Industries TB1013 designed for?

It is designed for 1.75-inch tubing, or 1-3/4 inches. Each tab is cut from 1/4-inch thick steel with a 1/2-inch bolt hole, and the hole center sits 1.25 inch from the top of the tube.

What comes with part number TB1013?

Two tabs come with the Artec Industries TB1013, sold as a pair. The UPC is 816791023629, and the part number is TB1013, so use both when checking that you have the right item.

How should the tabs be welded to round tubing?

Clean the contact area to bare metal, position the tab square to the tube, tack it in place, then weld both edges. Test-fit the bolt hole against the mating part first so the weld does not pull the mount out of line.
