Overview
The Trail Master 3.5-inch Lift Kit with NGS Shocks, model TM3335-40013, is a coil spring lift that raises the vehicle 3.5 inches front and rear. It includes front lower control arms, track bar brackets at both ends, and NGS shocks.
The front and rear track bar brackets are part of the kit’s geometry work. Trail Master lists both a front and a rear bracket, so the axle and the front end can be located correctly at the new height. The drop pitman arm is included for the steering linkage, and the sway bar end links keep the sway bar working at the lifted position.
Bump stop brackets position the bump stops for the 3.5-inch lift. Front lower control arms come with the kit, and the coil springs at both ends are the main part of the lift. Installation is straightforward, and the alignment should be set once the parts are fitted.
The lift is 3.5 inches, and the lift height range is 3 to 4.99 inches. The coil springs set the ride height at the front and rear.
Front lower control arms and sway bar end links are included to keep the front suspension located after the spring change.
Key features
- 3.5-inch lift
- Front and rear coil springs
- Front lower control arms
- Front and rear track bar brackets
- Bump stop brackets
- Sway bar end links
- Drop pitman arm
- NGS shocks
Track bars and steering geometry
Track bar brackets locate the axle side to side, so they matter more after a coil spring lift changes the suspension height. A front and rear bracket work together to keep the axle centered under the body, and the sway bar end links help keep the sway bar working at the new height. Drop pitman arms adjust steering linkage angles to suit the lifted front.
Because a lift changes the geometry of several parts, the alignment should be set after installation and rechecked after the first few drives. Look for uneven tire wear, a steering wheel that sits off center or a vehicle that wanders on the highway. Inspect track bar bushings and the drop pitman arm joints during routine service.
- Check track bar bushings for play.
- Inspect sway bar end link joints for wear.
- Look for uneven tire wear as an alignment sign.
Specifications
| Brand | Trail Master |
|---|---|
| Part number | TM3335-40013 |
| UPC | 614901082067 |
| Lift height | 3.5 inches |
| Lift height range | 3 to 4.99 inches |
| Suspension type | Coil spring kit |
| Shocks | NGS |
Vehicle fitment
No vehicle is named for this kit and no fitment list is available. Check Trail Master specifications for the model and year before choosing it.
Confirm your vehicle’s year, model and trim before ordering.
What’s included
Front and rear coil springs, front lower control arms, front and rear track bar brackets, bump stop brackets, sway bar end links, drop pitman arm and NGS shocks.
