Daystar 1.5 Inch Suspension Lift Kit – KJ09168BK

Daystar

Shop Jeep Renegade Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Lists the 2015–2017 Jeep Renegade
  • 1.5-inch bolt-on lift with coil spacers and stud extenders
  • Maintains the factory ride and stability
  • Designed for tires up to two sizes larger on stock wheels
  • Meets FMVSS 126

Description

Overview

The Daystar KJ09168BK is a 1.5-inch bolt-on suspension lift for the 2015–2017 Jeep Renegade. It uses coil spacers front and rear, along with front sway bar end links and rear control arm brackets, to raise the vehicle while keeping the factory ride.

The kit is 100 percent bolt-on and is designed to keep the factory ride and stability. It fits 2WD and 4WD Renegade models, and the actual lift can vary by model. It is FMVSS 126 compliant and is designed to fit up to two sizes of larger tires mounted on the stock wheels.

Because the kit does not include shocks, the factory shocks stay in use with the new lift height. Daystar’s installation instructions are included, and the kit carries the lifetime Go Everywhere warranty.

The actual lift can vary by model, so fit is judged on the specific Renegade rather than a single fixed height.

Key features

  • 100 percent bolt-on installation
  • Maintains the factory ride and stability
  • Front and rear coil spacers with front stud extenders
  • Front sway bar end links and rear control arm brackets included
  • FMVSS 126 compliant
  • Detailed installation instructions included

Shocks and what stays

Because the factory shocks stay in use, their condition matters more with a coil spacer lift. A worn shock that was adequate at stock height can feel harsh or bounce more once the body sits higher. Look for fluid on the shock body, split or missing bushings, and a shock that rebounds slowly after a bump.

The rest of the front and rear suspension is also affected by the change in height. Sway bar end links and control arm brackets are part of this kit, so those parts are installed together. After the lift, check brake hose length, ride height on both sides and steering centering, then recheck the bolts after a short drive.

  • Inspect shocks for leaks and worn bushings
  • Check brake hose slack after lifting
  • Retorque bolts after the first week of driving

Specifications

Brand Daystar
Part number KJ09168BK
UPC 618089005474
Lift height 1.5 inches (range 0 to 2.25 inches)
Suspension type Spacer
Rear lift method Spacers
Installation 100 percent bolt-on
Safety standard FMVSS 126 compliant
Shocks included No
Warranty Lifetime Go Everywhere warranty

Vehicle fitment

It is a direct fit for the 2015–2017 Jeep Renegade.

It covers the 2015–2017 Jeep Renegade only, in 2WD and 4WD form. Check your vehicle’s year, model and trim against those years before ordering.

Installation notes

The kit is 100 percent bolt-on and comes with detailed installation instructions. The sway bar end links and rear control arm brackets come with the spacers, so the kit goes on as one set.

What’s included

Two front coil spacers with stud extenders, two rear coil spacers, two front sway bar end links, two rear control arm brackets and detailed installation instructions.

Not included: Shocks.

SKU: DAYKJ09168BK Category:

Specification

Shipping weight 15.00 lbs
Package dimensions 20.00 × 15.00 × 15.00 in
brands

Fitment

VehicleYearsTrims
Jeep Renegade2015–201775th Anniversary, Dawn Of Justice, Latitude, Limited, Sport, Trailhawk

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the Daystar KJ09168BK fit a 2WD Jeep Renegade?

Yes. The kit fits 2WD and 4WD Renegade models within the 2015–2017 model years. The actual lift can vary by model.

How big a tire can I run with this lift?

The kit is designed to fit up to two sizes of larger tires on the stock wheels. The lift is 1.5 inches, with a range of 0 to 2.25 inches.

Is the KJ09168BK a bolt-on installation?

Yes. It is 100 percent bolt-on, and the kit comes with detailed installation instructions and all of its included parts.

Should the factory shocks be replaced with this lift?

The kit does not include shocks, so the factory shocks stay in use at the new lift height. Inspect them for leaks or worn bushings after installation, and replace any that are weak, since worn shocks reduce control on a lifted vehicle.

Do sway bar end links wear out?

Sway bar end links can wear at the ball joints and bushings, which causes clunking over bumps. Check them during service, and replace them as a pair when one is worn.
