Overview
The Daystar KJ09168BK is a 1.5-inch bolt-on suspension lift for the 2015–2017 Jeep Renegade. It uses coil spacers front and rear, along with front sway bar end links and rear control arm brackets, to raise the vehicle while keeping the factory ride.
The kit is 100 percent bolt-on and is designed to keep the factory ride and stability. It fits 2WD and 4WD Renegade models, and the actual lift can vary by model. It is FMVSS 126 compliant and is designed to fit up to two sizes of larger tires mounted on the stock wheels.
Because the kit does not include shocks, the factory shocks stay in use with the new lift height. Daystar’s installation instructions are included, and the kit carries the lifetime Go Everywhere warranty.
The actual lift can vary by model, so fit is judged on the specific Renegade rather than a single fixed height.
Key features
- 100 percent bolt-on installation
- Maintains the factory ride and stability
- Front and rear coil spacers with front stud extenders
- Front sway bar end links and rear control arm brackets included
- FMVSS 126 compliant
- Detailed installation instructions included
Shocks and what stays
Because the factory shocks stay in use, their condition matters more with a coil spacer lift. A worn shock that was adequate at stock height can feel harsh or bounce more once the body sits higher. Look for fluid on the shock body, split or missing bushings, and a shock that rebounds slowly after a bump.
The rest of the front and rear suspension is also affected by the change in height. Sway bar end links and control arm brackets are part of this kit, so those parts are installed together. After the lift, check brake hose length, ride height on both sides and steering centering, then recheck the bolts after a short drive.
- Inspect shocks for leaks and worn bushings
- Check brake hose slack after lifting
- Retorque bolts after the first week of driving
Specifications
| Brand | Daystar |
|---|---|
| Part number | KJ09168BK |
| UPC | 618089005474 |
| Lift height | 1.5 inches (range 0 to 2.25 inches) |
| Suspension type | Spacer |
| Rear lift method | Spacers |
| Installation | 100 percent bolt-on |
| Safety standard | FMVSS 126 compliant |
| Shocks included | No |
| Warranty | Lifetime Go Everywhere warranty |
Vehicle fitment
It is a direct fit for the 2015–2017 Jeep Renegade.
It covers the 2015–2017 Jeep Renegade only, in 2WD and 4WD form. Check your vehicle’s year, model and trim against those years before ordering.
Installation notes
The kit is 100 percent bolt-on and comes with detailed installation instructions. The sway bar end links and rear control arm brackets come with the spacers, so the kit goes on as one set.
What’s included
Two front coil spacers with stud extenders, two rear coil spacers, two front sway bar end links, two rear control arm brackets and detailed installation instructions.
Not included: Shocks.
