Overview
The TeraFlex 4838100 is a heavy-duty hinged tire carrier for 2 and 4-door Jeep models that holds a spare tire up to 37 inch. It mounts at the factory tailgate hinge points rather than a single hinge, so the spare tire load is spread across more than one point and the carrier works with the existing tailgate structure.
The main component is cast A356.2 T6 aluminum, which keeps the carrier light while preserving strength. The carrier follows the flow and contour of the Jeep body, and its threaded holes accept accessories such as fuel cans and a recovery jack. The design spreads the spare tire load across the tailgate hinge points, reducing stress on the gate and keeping one-handed access to the rear cargo area.
Key features
- Cast A356.2 T6 aluminum main component, light yet strong
- Forged steel hinge brackets with 5/8 inch high-carbon hardened steel hinge pins
- Uses the factory tailgate hinge mounting points, no drilling required
- Carries the weight of the tailgate assembly and spare tire to reduce stress on the gate
- Threaded mounting holes for fuel cans, a recovery jack and similar accessories
- Keeps single one-handed entry to the Jeep cargo area
- Works with OE and aftermarket bumpers, so an aftermarket bumper is not required
Before you mount a spare
A hinged carrier turns the tailgate into a load-bearing point, so the spare’s weight moves through the factory hinges. Before mounting, check the tailgate hinge points, the body mount and the bolts for wear. A carrier that fits well keeps the spare aligned and prevents the gate from sagging when it is opened.
Accessories on the threaded holes, such as fuel cans or a recovery jack, add weight and reach. Choose them with the carrier’s load in mind and keep the heaviest items closest to the body. Recheck the bolts and hinge pins after the first drives, and look for cracks around the aluminum casting.
- Check hinge points before mounting
- Keep heavy accessories close to the body
- Recheck bolts after the first drives
Specifications
| Brand | TeraFlex |
|---|---|
| Part number | 4838100 |
| UPC | 843885029847 |
| Carrier type | Heavy-duty adjustable hinged tire carrier |
| Maximum tire size | 37 inch |
| Main component | Cast A356.2 T6 aluminum |
| Hinge brackets | Forged steel |
| Hinge pins | 5/8 inch, cold formed high-carbon hardened steel |
| Vehicle type | 2 and 4-door models |
| Mounting | Factory tailgate hinge points and body mount |
Vehicle fitment
It mounts to 2 and 4-door Jeep models that use factory tailgate hinge mounting points. Match your year, model and body style to that before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Mounting uses the factory tailgate hinge points and body mount, and no drilling is needed. Common hand tools are enough for installation. Because the carrier takes the weight of a 37 inch spare, have a helper support it while it is fastened to the gate.
What’s included
It includes spacers, installation hardware and installation instructions.
