Raceline Wheels 946B Boost, 17x9 with 8 on 170 Bolt Pattern – Satin Black – 946B-79081-12

Raceline Wheels

Shop Raceline Wheels 17x9 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Raceline Wheels 946B Boost, 17×9 aluminum spoke wheel, part RLW946B-79081-12
  • Bolt pattern 8 on 170 with offset -12 and center bore 131
  • Backspacing 4.5, satin black finish
  • Labeled Universal Fit; no vehicle is named

Description

Overview

The Raceline Wheels 946B Boost is a 17 inch by 9 inch aluminum spoke wheel in satin black, part number RLW946B-79081-12. It sits in the 946 Boost series with an 8 on 170 bolt pattern, and the brand tags it Universal Fit rather than naming a vehicle.

Raceline Wheels describes its consumer wheel line as built on the same performance technology used in its off-road racing wheels. For fitment, compare offset -12, center bore 131 and backspacing 4.5 against your own hub and clearance.

Key features

  • 17 inch diameter and 9 inch width
  • Aluminum spoke style
  • Satin black finish
  • Bolt pattern 8 on 170
  • Offset -12, backspacing 4.5 and center bore 131
  • Part of the 946 Boost series

Wheel offset and clearance

Offset and backspacing decide where a wheel sits relative to the hub, the fender and the suspension. A wheel with a negative offset pushes its face outward, which can change tire-to-fender clearance and steering-arm clearance. Backspacing shows how far the mounting face sits from the inner lip, so it is the number to check against brake calipers and the inside of the wheel.

Aluminum spoke wheels are often chosen for appearance and reduced weight, but the spoke design also affects how brake dust and debris clear. Clean the back of the wheel during regular service. Tire choice matters too: a tire of the wrong overall diameter changes speedometer reading and can rub at full lock.

  • Check brake caliper clearance before mounting
  • Use a tire with the correct overall diameter
  • Recheck lug torque after the first drives

Specifications

Brand Raceline Wheels
Part number RLW946B-79081-12
Series 946 Boost
Wheel diameter 17 Inches
Wheel width 9 Inches
Offset -12
Center bore 131
Backspacing 4.5
Bolt pattern 8 on 170
Style Spoke
Construction Aluminum
Finish Satin Black
Fitment label Universal Fit

Vehicle fitment

Matching the 8 on 170 bolt pattern and center bore 131 to your hub comes first, then confirm suspension and brake clearance for the -12 offset.

A matching bolt pattern and center bore do not confirm clearance for offset -12 on every vehicle. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Measure the hub bolt pattern and center bore before ordering. A negative offset of -12 moves the mounting face outward, so check suspension and brake clearance, and test fit the wheel with a tire mounted before driving.

What’s included

Plan on arranging tires, center caps and lug nuts separately for a complete setup.

Not included: Lug hardware, caps and tires are not part of the wheel itself.

SKU: RLW946B-79081-12 Categories: ,

Questions & Answers

Is the Raceline 946B Boost vehicle specific?

No. It carries a Universal Fit label and has no vehicle, year or chassis code. Match the 8 on 170 bolt pattern, 131 center bore, offset -12 and 4.5 backspacing to your hub before buying.

What size is part RLW946B-79081-12?

It is 17 inches in diameter and 9 inches wide, in the 946 Boost series from Raceline Wheels. The wheel is aluminum, spoke style, with a satin black finish, offset -12, center bore 131 and backspacing 4.5.

Are tires or caps included with the wheel?

Tires, center caps and lug nuts are not part of this wheel. Plan to arrange them yourself and confirm all contents before ordering.

Do I need hub-centric rings with this wheel?

Only if the hub bore is larger than the wheel's center bore. Hub-centric rings fill the gap so the wheel centers on the hub rather than on the lug studs. Check the hub bore before ordering, and confirm the rings fit snugly.

How often should lug nuts be rechecked on new wheels?

Recheck lug nut torque after the first few drives and again at regular service intervals. New wheels can settle against the hub, so a second check helps prevent loosening. Use the torque specification for your vehicle.
