Pro Comp 6 Inch Stage I Lift Kit with ES3000 Shocks – K1010

Pro Comp Suspension

Shop GMC K15 Suburban Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 6-inch stage I lift for 1977-1978 Chevrolet and GMC C/K trucks
  • ES3000 front and rear shocks
  • Steering arm correction and extended-length brake lines
  • Part number K1010

Description

Overview

The Pro Comp 6 Inch Stage I Lift Kit with ES3000 Shocks, part number K1010, is a 6-inch lift for 1977-1978 Chevrolet and GMC C/K trucks and their Blazer, Jimmy and Suburban versions. The front uses leaf springs and U-bolts, and the rear uses a block and U-bolt kit with add-a-leaf components. ES3000 shocks are listed at both ends.

Steering correction is handled with a steering arm, and extended-length brake lines are included. The lift height range is 5 to 6.99 inches.

Key features

  • 6-inch stage I lift
  • Front leaf springs and U-bolts
  • Steering arm steering correction
  • Rear block and U-bolt kit with add-a-leaf springs
  • ES3000 front and rear shocks
  • Extended-length brake lines

Steering arm and alignment check

A steering arm changes the geometry of the front steering, so the joints and linkage should be inspected before the kit goes on. Worn ball joints, tie rod ends and pitman or idler arm bushings can make the truck wander and feel loose after the lift. Replacing these parts during installation is a common choice for trucks of this age.

A six-inch leaf spring lift also raises the center of gravity, which changes how the truck handles in turns and on uneven ground. Drive carefully after the install and allow for a longer stopping distance. Recheck the steering and suspension bolts after the first few drives, and look for fresh grease or leaks at the joints.

  • Check ball joints and tie rod ends before installation
  • Recheck bolts after the first few drives
  • Watch for uneven tire wear after alignment
  • Allow extra room for braking on uneven ground

Specifications

Brand Pro Comp Suspension
Part number K1010
UPC 614901122084
Lift height 6 inches, stage I
Lift height range 5 to 6.99 inches
Front suspension Leaf springs and U-bolts
Steering correction Steering arm
Rear lift Block and U-bolt kit with add-a-leafs
Shocks ES3000, front and rear (shock boots not included)
Fitment Direct fit

Vehicle fitment

The kit fits the 1977-1978 Chevrolet K10 and K10 Suburban, the 1977-1978 Chevrolet K5 Blazer, the 1977-1978 GMC Jimmy, the 1977-1978 GMC K15, and the 1975-1978 GMC K15 Suburban.

Trucks from 1973 to 1974 and from 1979 on are not on this list, and the 1975-1976 entry is the GMC K15 Suburban. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

A 6-inch leaf spring lift with a steering arm changes alignment and steering geometry, so have the alignment checked after the kit is installed.

What’s included

The kit includes front leaf springs and U-bolts, a steering arm, a rear block and U-bolt kit with add-a-leaf springs, ES3000 shocks, and extended-length brake lines. Shock boots are not included.

SKU: EXPK1010 Category:

Specification

Shipping weight 190.83 lbs
Package dimensions 0.00 × 0.00 × 0.00 in
brands

Fitment

VehicleYearsTrims
Chevrolet K101977–1978Cheyenne, Custom Deluxe, Scottsdale, Silverado
Chevrolet K10 Suburban1977–1978Custom Deluxe, Scottsdale, Silverado
Chevrolet K5 Blazer1977–1978Cheyenne, Custom Deluxe, Silverado
GMC Jimmy1977–1978Base, High Sierra, Sierra Classic, Sierra Grande
GMC K151977–1978Base, High Sierra, Indy Hauler, Sierra Classic, Sierra Grande
GMC K15 Suburban1975–1978Base, High Sierra, Sierra Classic, Sierra Grande

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the K1010 fit a 1978 Chevrolet K10?

Yes. The kit fits the 1977-1978 Chevrolet K10, and a 1978 model falls within that range. The K10 pickup, Suburban and Blazer versions are covered for those years.

Does the K1010 need a steering arm?

Yes. The kit includes a steering arm, which is the steering correction for these Chevrolet and GMC trucks. The arm is supplied with the kit as the correction for the trucks it fits.

Does the K1010 come with extended brake lines?

Yes. Extended-length brake lines are included with the kit, matching the higher ride height. Check hose routing once the truck is raised, and confirm fit for your vehicle's year, model and trim before ordering.

How do I know if my steering arm needs replacing?

Look for play at the arm's joints, uneven tire wear, or a steering wheel that drifts while driving. Lift the front and check for movement at the connections. Any looseness should be fixed before the alignment is set.
