Poison Spyder TJ BFH Body Mounts – 14-51-030

Poison Spyder Customs

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Poison Spyder TJ BFH body mounts, part number 14-51-030
  • Fits the Wrangler TJ and the 2004 to 2006 Wrangler LJ
  • 3/16 inch CNC laser-cut plate steel
  • Ramp-shaped design to slide up and over rocks
  • Small drain holes keep water and mud from pooling

Description

Overview

The Poison Spyder TJ BFH Body Mounts, part number 14-51-030, are extreme duty replacement body mounts made from 3/16 inch plate steel. They fit the Jeep Wrangler TJ and the 2004 to 2006 Jeep Wrangler LJ, Unlimited and Unlimited Rubicon. Poison Spyder designed the mounts to act as a ramp that helps the Jeep slide up and over rocks, rather than acting as an anchor that holds the vehicle back the way stock mounts can. They are meant to replace body mounts that have been damaged on the trail.

Poison Spyder designed the mounts to act as a ramp that helps the Jeep slide up and over rocks, rather than acting as an anchor that holds the vehicle back the way stock mounts can. They are meant to replace body mounts that have been damaged on the trail.

Key features

  • CNC laser-cut from 3/16 inch plate steel
  • Ramp-shaped profile to help the Jeep slide over rocks
  • Small drain holes to keep water and mud from pooling inside
  • Extreme duty replacement for damaged stock mounts

Removing and checking stock mounts

Before a new mount goes in, the old one has to come out cleanly. Support the body properly, loosen the fasteners in a planned order, and inspect the mounting area while the old part is off. Look for cracks in the frame brackets, rust that has eaten into the metal, and rubber isolators that have hardened or split. Any damage found at this stage should be repaired before the replacement is bolted in.

A replacement mount only does its job if the surface beneath it is sound and clean. Wire brush the contact points, replace stretched or corroded hardware, and make sure the new part sits flat without forcing it. Recheck the fasteners after the first few trail runs, since shifting under load can loosen them.

  • Support the body before loosening fasteners
  • Inspect frame brackets for cracks and rust
  • Replace corroded or stretched hardware
  • Recheck torque after the first trail runs

Specifications

Brand Poison Spyder Customs
Part number 14-51-030
UPC 614901726077
Type Replacement body mount
Material 3/16 inch plate steel
Construction CNC laser-cut
Drainage Small drain holes

Vehicle fitment

These mounts fit the Jeep Wrangler TJ and the 2004 to 2006 Jeep Wrangler LJ, Unlimited and Unlimited Rubicon. Confirm your Jeep is a TJ or an LJ before ordering, and compare the old mounts with the new ones before removing anything.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

The drain holes let water and mud run out of the mount rather than collect in it.

What’s included

One replacement body mount in CNC laser-cut 3/16 inch plate steel.

SKU: PSC14-51-030 Category:

Specification

Shipping weight 14.00 lbs
Package dimensions 14.00 × 8.00 × 6.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (LJ)2004–2006Unlimited, Unlimited Rubicon
Jeep Wrangler (TJ)1997–200665th Anniversary Edition, Rubicon, SE, Sahara, Sport, X

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Are the TJ BFH body mounts 14-51-030 for a TJ?

Yes. They fit the Jeep Wrangler TJ, along with the 2004 to 2006 Wrangler LJ. Confirm your Jeep is one of those two models before ordering.

How do these differ from stock body mounts?

The stock mounts act as anchors that can hold the Jeep back on rocks. These are shaped as a ramp to help the Jeep slide up and over rocks instead.

Do they have drain holes?

Yes. Small drain holes let water and mud run out, so the mount does not hold moisture or debris after a trail run.

Is the mount made of steel or aluminum?

It is made from 3/16 inch plate steel, CNC laser-cut to shape. No finish is listed, so check the mount for coating before installing it.

What should I check on the frame before fitting a new mount?

Look at the mounting points for cracks, rust and bent brackets before bolting anything in place. Clean the contact surfaces so the mount sits flat, and replace any hardware that is stretched or corroded. A cracked frame area needs repair before a new mount goes on.
