Overview
The Poison Spyder Stock Crusher Corners in bare steel (part number 12-04-010) are body corner guards cut from high strength 3/16 inch plate steel. Each corner is laser cut and then roll formed to follow the body lines of the Jeep.
The stock layout includes the factory wheel and fuel filler opening, along with mounting holes for all of the factory equipment, including the factory flares, tail light and license plate frame. The corners are not coated and ship as bare steel.
Key features
- High strength 3/16 inch plate steel
- Roll formed to the body lines of the Jeep
- Openings for the factory wheel and fuel filler
- Mounting holes for the factory flares, tail light and license plate frame
- Countersunk bolt holes for a flat surface that slides over rocks
Bare steel corner care
Bare steel corners rely on their surface to resist rust, and that surface wears quickly when rocks and mud scrape it. Once the corners are fitted, light scratches are the first place rust begins. Inspecting the corners after trail use and touching up bare spots early keeps the steel in good shape.
Corners also work with the rest of the body guard setup, so check the bolts and flat head screws for tightness after the first outings. Wet, salty ground can speed corrosion around cut edges, so rinse the corners and dry them thoroughly. A coat of paint or a protective finish can be applied before fitting if a matched look is wanted.
- Inspect corners after rough trail use
- Touch up scratches to stop early rust
- Check screw tightness after the first outings
Specifications
| Brand | Poison Spyder Customs |
|---|---|
| Part number | 12-04-010 |
| UPC | 614901723724 |
| Type | Body corner guard, stock layout |
| Corner type | Full |
| Material | 3/16 inch plate steel |
| Finish | Bare steel |
| Hardware | Stainless steel flat head cap screws |
| Installation type | Cutting or drilling required |
Vehicle fitment
The corner is cut to follow the body lines of the Jeep, so the vehicle model decides the fit. Confirm fit for your vehicle’s year, model and trim before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Installation requires cutting or drilling. The stainless steel flat head cap screws supplied with the corner are what hold it in place on the body.
What’s included
Stock Crusher Corners in bare steel and the stainless steel flat head cap screws.
Not included: any coating or paint, since the corners ship bare.
