Overview
The Motive Gear MIDD44-456RJK is a reverse cut front ring and pinion with a 4.56 ratio for Dana 44 JK front axles. It is a light duty replacement built from 8620 steel, suited to on road and off road driving. It applies to the Jeep Wrangler JK through its Dana 44 JK front axle type.
Key features
- 4.56 gear ratio for Dana 44 JK front axles
- Reverse cut gear design.
- Made from 8620 steel with CNC throughout
- Computer controlled heat treatment
Reverse cut gears explained
Reverse cut is a tooth design used in some ring and pinion sets. Because it changes the direction the gear teeth face, the set must match the axle rotation and carrier direction, so confirm rotation before installing. Understanding the design helps when comparing parts with the same ratio.
Front gear sets need careful alignment, and pinion depth and carrier preload must be set correctly before the axle returns to service. Keep track of shim positions, check the contact pattern, and listen for noise during a low speed test drive. New reverse cut gears also benefit from a gentle break-in.
- Confirm rotation matches the front axle
- Set pinion depth before preload
- Check contact pattern with marking compound
- Test drive at low speed first
Specifications
| Brand | Motive Gear |
|---|---|
| Part number | MIDD44-456RJK |
| Gear ratio | 4.56 |
| Axle manufacturer | Dana |
| Axle type | Dana 44 JK |
| Axle location | Front |
| Gear cut | Reverse cut |
| Gear material | 8620 steel |
Vehicle fitment
This gear is for the Jeep Wrangler JK, since it uses the Dana 44 JK front axle type.
Rear axle gears and other Wrangler generations fall outside this part. Verify your year, model and trim match before ordering.
Installation notes
Gear mesh and bearing preload must be set correctly for a front ring and pinion, so professional setup is the safest route. New gears also need a break-in period.
What’s included
Only the front ring and pinion gear set is described.
Not included: Check carrier and pinion bearings and installation hardware against your build before starting.
