Overview
This Double Standard MR304 17×8.5 is a black aluminum spoke wheel with an 8 on 170 bolt pattern, part number MRWMR30478587500. It belongs to the off-road racing range and is not tied to a single vehicle.
The wheel was engineered and checked for its intended use with finite element analysis and field testing. Its aim is less weight and more strength for demanding terrain.
Key features
- 17-inch by 8.5-inch spoke wheel
- 8 on 170 bolt pattern with a 131 center bore
- Offset 0, backspacing 4.75
- Black finish on aluminum
- Part of the MR304 Double Standard series
- Designed for off-road racing, per the brand
Lug seats and stud checks
Lug studs carry the wheel’s full load, so their condition matters as much as the wheel itself. Inspect studs for stretched threads, rust at the base and damaged knurling before fitting new wheels. Replacing a stud is simple on many vehicles, while a stud that has been overtightened may need the hub removed for proper service.
Wheel nuts should match the seat type of the wheel. Using a nut with the wrong taper or seat can leave the wheel loose even when the nut feels tight. Hand-start every nut to avoid cross-threading, tighten in a star pattern, and recheck after the first drive on new wheels.
- Check for rust between the hub and wheel
- Inspect studs for stretched or damaged threads
- Replace nuts that show rounding on the hex
Specifications
| Brand | Method Race Wheels |
|---|---|
| Part number | MRWMR30478587500 |
| Series | MR304 Double Standard |
| Wheel diameter | 17 Inches |
| Wheel width | 8.5 Inches |
| Bolt pattern | 8 on 170 |
| Center bore | 131 |
| Offset | 0 |
| Backspacing | 4.75 |
| Style | Spoke |
| Construction | Aluminum |
| Finish | Black |
Vehicle fitment
This is a universal fit wheel, so no vehicle is tied to it. The 8 on 170 bolt pattern and 131 center bore decide whether the wheel suits a given hub, and the 0 offset and 4.75 backspacing set how far it sits in the fender.
Review the 0 offset and 4.75 backspacing too, because they govern how far the wheel sits in the fender.
Confirm your vehicle’s year, model and trim before ordering.
What’s included
One wheel is included and nothing else.
Not included: Tires, wheel nuts and valve stems are not included and must be purchased separately.
