Overview
The Method Race Wheels 701HD Trail Series 18×9 is a windowed aluminum wheel with an 8 on 6.5 bolt pattern and a Bronze finish, part number MRWMR70189080918H. It is built for off-road trail use, with an 18 inch diameter, 9 inch width, 18 offset, 131 center bore and 5.75 backspacing. It is a universal design, so it is not tied to one vehicle model.
The wheel is one-piece cast from 356 aluminum and heat treated to T6. Its patent-pending Bead Grip technology engages the tire bead seat for more grip at lower air pressures. A reinforced inner lip adapted from race wheel design and aggressive safety humps on both bead seats help keep the tire stable and resist de-beading. It was engineered with finite element analysis and field testing to lower weight and raise strength.
Key features
- One-piece cast 356 aluminum construction with T6 heat treatment
- Patent-pending Bead Grip technology for added tire grip at lower air pressures
- Reinforced inner lip adapted from race wheel design
- Aggressive safety humps on the inner and outer bead seat to help prevent de-beading
- Windowed style in a Bronze finish
- Engineering used finite element analysis and field testing.
Test fit and clearance
A test fit should come before the tire goes on, so you can see the real clearance. Mount the wheel with the hub hardware you plan to use, then check the brake caliper, the rotor edge and the suspension arms. A wheel that clears in the shop can still rub under load or at full compression.
Bronze finishes show scratches differently than black ones, so protect the face during the test fit with a soft cloth. Recheck clearance after changing tire size or adding a lift, since small changes in offset and tire height can bring the tire into contact with the fender edge.
- Test-fit before mounting the tire
- Check caliper and rotor clearance at full lock
- Retest after any tire or suspension change
Specifications
| Brand | Method Race Wheels |
|---|---|
| Part number | MRWMR70189080918H |
| Series | MR701 HD (701 Trail Series) |
| Wheel diameter | 18 inches |
| Wheel width | 9 inches |
| Bolt pattern | 8 on 6.5 |
| Offset | 18 |
| Center bore | 131 |
| Backspacing | 5.75 |
| Style | Windowed |
| Finish | Bronze |
| Construction | Aluminum, one-piece cast 356 with T6 heat treatment |
Vehicle fitment
This wheel is not tied to a specific vehicle, so no year, make, model or trim is attached. Choose it by comparing the 18 inch diameter, 9 inch width, 8 on 6.5 bolt pattern, 18 offset, 131 center bore and 5.75 backspacing with your vehicle’s hub and clearance needs.
Universal fit does not confirm clearance for brakes, suspension or fenders. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Test-fit the 18 offset and 5.75 backspacing with the tire you plan to run, since a wheel with the right bolt pattern can still rub or fail to clear the brakes.
