Method Race Wheels 309 Grid, 17x8.5 with 5 on 5 Bolt Pattern – Titanium / Black – MR30978550800

Method Race Wheels

$259.94In stock
Buy on Amazon

See similar parts on Amazon

Price and availability as of Nov 18, 2026 10:10 AM MST, from Amazon.com, and subject to change. The Amazon listing has the current details.

Check out with your Amazon account. Amazon handles delivery and returns.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Method Race Wheels 309 Grid, 17×8.5 aluminum mesh wheel listed at 5 on 5 bolt pattern
  • Part number MRWMR30978550800
  • Center bore 94, offset 0, backspacing 4.75
  • Titanium / Black per title; specifications list Gray
  • Universal fit; verify the 5 on 5 bolt pattern before mounting.

Description

Overview

The Method Race Wheels 309 Grid is a 17×8.5 inch aluminum mesh wheel with a 5 on 5 bolt pattern and part number MRWMR30978550800. Its center bore is 94, offset 0 and backspacing 4.75.

The 309 Grid is an off-road wheel from the MR309 series. Method Race Wheels checks its designs with finite element analysis and field testing, aiming for a wheel that is lighter and stronger. It is universal fit, so the hub must be measured against the 5 on 5 bolt pattern and 94 center bore before mounting.

Key features

  • Aluminum mesh face in a 17 by 8.5 inch size
  • Bolt pattern is 5 on 5.
  • Center bore of 94
  • Offset of 0 and backspacing of 4.75
  • The finish is gray; the title also names Titanium / Black.
  • The wheel was developed with finite element analysis and field testing.

Measuring a hub before mounting

Before a wheel goes on, measure the hub instead of trusting a single figure. Check the lug pattern across opposite studs, confirm the hub bore size, and compare both with the wheel’s center bore. A small mismatch in the bore can cause vibration that feels like a balance problem, so the check is worth the few minutes it takes.

Lug seat style matters as much as the pattern. A seat that does not match the wheel can let a lug loosen, so match the nut to the wheel’s lug holes. Tighten in a star pattern and re-check torque after the first few drives, and recheck when tires are rotated.

  • Measure stud spacing across opposite studs
  • Confirm hub bore against the wheel bore
  • Use seats that match the wheel lug holes
  • Re-check torque after the first drives

Specifications

Brand Method Race Wheels
Part number MRWMR30978550800
Series MR309 Grid
Wheel diameter 17 inches
Wheel width 8.5 inches
Bolt pattern 5 on 5
Center bore 94
Offset 0
Backspacing 4.75
Style Mesh
Finish Gray (title: Titanium / Black)
Construction Aluminum
Fitment Universal Fit

Vehicle fitment

Fitment is not tied to a named vehicle. The specifications list Universal Fit, so the wheel has to be checked against the hub by measurement; the 5 on 5 pattern in particular should be confirmed on the vehicle before a tire is fitted.

Compare the bolt pattern, center bore and offset with the vehicle’s requirements. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Measure the hub’s lug layout before mounting rather than relying on the listed figure alone. Use lug nuts whose seat style suits the wheel and tighten them in a star pattern, since uneven lug torque can warp a wheel.

What’s included

Hardware, caps and tires are not part of this wheel. Compare the contents with your install plan first.

SKU: MRWMR30978550800 Categories: ,

Questions & Answers

What is the Method Race Wheels 309 Grid MRWMR30978550800?

It is a 17x8.5 inch aluminum mesh wheel from Method Race Wheels, part number MRWMR30978550800. The listed bolt pattern is 5 on 5, with a center bore of 94, offset 0 and backspacing 4.75.

Is this wheel made for a particular vehicle?

It is a universal-fit wheel with no vehicle named. Confirm the 5 on 5 bolt pattern and 94 center bore against your hub before mounting.

Why does the finish show two colors?

The finish is gray, though the title also reads Titanium / Black. Compare the color before ordering if the shade matters.

What do the offset and backspacing numbers mean here?

The offset is 0 and the backspacing is 4.75. Together with the 94 center bore, these measurements affect how the wheel sits against the hub and brake components.

Does finish affect performance?

No. Finish is a cosmetic choice and does not change fit or strength. Clean the surface with mild soap so debris does not hide cracks or scratches.
