Overview
The Method Race Wheels 305 NV 20×9 in bronze and black is an aluminum off-road wheel with an 8 on 170 bolt pattern, part number MRWMR30529087918. Method Race Wheels says each wheel is designed for its use, with the structure checked by finite element analysis and field trials.
The wheel is made to reduce weight and gain strength. Street wheels in the range come in Diamond Cut / Clear or Matte Black. This version has an 18 offset, 5.75 backspacing and a 131 center bore.
Key features
- Bronze/Black finish on a windowed MR305 NV design
- Aluminum construction, 20 by 9 inches
- 8 on 170 bolt pattern with a 131 center bore
- Offset of 18 and backspacing of 5.75
- Engineered for off-road use by the brand
Brake and caliper clearance
Brake calipers and rotors set the minimum inside clearance for any wheel. Offset controls how far the wheel sits in or out, so the same wheel can clear one brake setup and rub another. Measure the caliper and rotor size before buying, and compare the wheel’s inside face with the caliper body at full steering lock.
Bronze finishes show brake dust differently than black, and dust can build up in the inner barrel where it is hard to see. Clean the inside of the spokes when brakes are serviced. Upgraded pads or larger rotors can reduce clearance, so re-check fit after any brake job.
- Measure caliper and rotor diameter
- Check inside clearance at full lock
- Re-check fit after brake upgrades
Specifications
| Brand | Method Race Wheels |
|---|---|
| Part number | MRWMR30529087918 |
| Series | MR305 NV |
| Style | Windowed |
| Finish | Bronze/Black |
| Construction | Aluminum |
| Wheel diameter | 20 inches |
| Wheel width | 9 inches |
| Bolt pattern | 8 on 170 |
| Center bore | 131 |
| Offset | 18 |
| Backspacing | 5.75 |
Vehicle fitment
No vehicle fitment is tied to this 20×9 wheel. It carries a Universal Fit designation, so the 8 on 170 pattern and 131 center bore need to be compared with your hub.
Confirm fit for your vehicle’s year, model and trim before ordering. Measure your hub’s 8 on 170 pattern and 131 center bore before installing.
Installation notes
The 8 on 170 pattern and 131 center bore must match the hub before the wheel is installed. Check caliper and fender clearance with the 18 offset before the tires are fitted.
What’s included
The wheel is the only item covered here. Tires, wheel hardware and center caps are not part of it.
