Overview
The Method Race Wheels 305 NV HD in 18×9 with a Bronze / Black finish is an aluminum windowed wheel with an 8 on 6.5 bolt pattern and part number MRWMR30589080918H. It is 9 inches wide with an 18-inch diameter, a center bore of 131, an offset of 18 and a backspacing of 5.7.
HD is part of the series name, and the MR305 NV HD line is developed with finite element analysis and field testing for lighter, stronger designs. The 8 on 6.5 pattern is a different layout from the 8 on 170 wheels in the same series.
Key features
- Bronze / Black finish
- Windowed style with aluminum construction
- 8 on 6.5 bolt pattern with a 131 center bore
- Offset 18 and backspacing 5.7
- MR305 NV HD series designation
Matching the bolt pattern
Bolt pattern is the first thing to match. Two wheels in the same series can use different layouts, so an 8 on 6.5 wheel will not mount to an 8 on 170 hub. Check the hub’s stud count and spacing directly, and use a measuring tool across the studs when the pattern is unclear.
Offset and backspacing decide how the wheel sits against the fender, brakes and steering. Tire width and sidewall height change that room, so test fit with the planned tire at full steering lock. Center bore should match the hub or use hub-centric rings. Bronze and black finishes show brake dust, so rinse the spokes regularly. Replace a wheel that shows cracks or bent beads.
Lug nut seat style matters as well. Conical seats and ball seats are not interchangeable, and using the wrong nut can loosen the wheel. Inspect lug holes for elongation, and retighten nuts after the first trail runs.
Specifications
| Brand | Method Race Wheels |
|---|---|
| Part number | MRWMR30589080918H |
| Series | MR305 NV HD |
| Style | Windowed |
| Construction | Aluminum |
| Finish | Bronze / Black |
| Wheel diameter | 18 inches |
| Wheel width | 9 inches |
| Bolt pattern | 8 on 6.5 |
| Center bore | 131 |
| Offset | 18 |
| Backspacing | 5.7 |
Vehicle fitment
No specific vehicle is named for this wheel. An 8 on 6.5 pattern is a different hub layout from the 8 on 170 wheels, so compare the pattern with your vehicle’s hub before mounting.
The 8 on 6.5 and 8 on 170 patterns in this series are separate products; confirm your bolt pattern before ordering.
Installation notes
The 131 center bore and 8 on 6.5 pattern must match the hub. Use the offset of 18 and backspacing of 5.7 to check clearance with the planned tire and brake setup.
What’s included
Lug nuts, caps and valve stems are not confirmed with this wheel. Verify the package contents before ordering additional hardware.
Not included: Tires.
