Overview
The Fab Fours GM14-C3152-1 is a front winch bumper with sensor holes and a Pre-Runner guard. It is a steel bumper with a black powder coat, and its winch tray accepts winches of up to 16,500 lb.
Fab Fours says its Premium winch bumpers have a redesigned center section with four integrated sensor holes to work with factory equipped sensors. The holes are laser cut in the factory pattern and compatible with the OEM sensor housing, so matching front and rear steel bumpers work with the factory park assist system.
The internal winch tray has a new D-ring and fairlead location. Access slots in the lower portion of the tray let the factory sensor harness pass through.
Key features
- Pre-Runner guard winch bumper with sensor holes
- Four laser cut sensor holes in the factory pattern
- Compatible with the OEM sensor housing
- Access slots in the winch tray for the factory sensor harness
- Winch ready for winches up to 16,500 lb
- 3/4-inch D-ring mounts
- 90mm fog lights and 60mm turn indicators included
- Adjustable 1/4-inch boxed mounting system
- Made in the USA
Guard styles and sensor layout
A Pre-Runner guard sits in front of the bumper face and protects the grille and lights from brush and low obstacles. It also adds tire clearance on some setups, which can reduce rubbing on turns. On a sensor version, the guard should not block the sensor holes, so check the guard and bumper together before adding any accessory to the face.
When choosing a guard style, think about the use. A guard suits trail driving and frequent low obstacles, while a plainer face is easier to clean for road use. Keep the sensor housings seated and the harness clear of the guard tubes, and inspect the welds after rough runs. Where the bumper is used with recovery gear, confirm the winch mount and fairlead work with the guard in place.
Specifications
| Brand | Fab Fours |
|---|---|
| Part number | GM14-C3152-1 |
| UPC | 5810109523 |
| Product type | Front winch bumper with sensor holes and Pre-Runner guard |
| Position | Front |
| Width | Full |
| Material | Steel, 1/4-inch and 3/16-inch combination |
| Finish | 2 stage matte black powder coat |
| Winch capacity | 16,500 lb winch or smaller |
| D-ring mounts | 3/4-inch |
| Lights | 90mm fog lights and 60mm turn indicators |
| Sensor holes | Four, laser cut, factory pattern |
| Winch mount | Included |
Vehicle fitment
Confirm the year, model and trim match your truck before ordering.
Check the part number and layout against any other GM14 bumper before assuming they match.
Installation notes
The factory sensor harness passes through access slots cut into the lower portion of the winch tray. The boxed mounting system adjusts for fit.
What’s included
- Front winch bumper with Pre-Runner guard
- Winch mount
- 90mm fog lights
- 60mm turn indicator lights
- Sensor holes cut to the factory pattern
Not included: The winch, the factory sensors and wiring.
