Bushwacker Ford Cut-Out Rear Fender Flares (Paintable) – 20022-11

Bushwacker

Shop Ford Bronco Fender Flares on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Cut-Out Style rear fender flares for Ford trucks, pair of rear flares
  • 3.75 inches of width and tire coverage
  • Sheet metal removal maximizes wheel articulation
  • OEM matte black finish that is easy to paint
  • Fits Ford Bronco, F-150, F-250 and F-350 models in the 1990s

Description

Overview

The Bushwacker Cut-Out Style rear fender flare pair, part 20022-11, is made for the Ford Bronco and F-Series trucks. Each Cut-Out set is built to free up off-road wheel travel while keeping tire coverage. This pair adds 3.75 inches of width and tire coverage at the rear and fits the 1992 to 1997 model years.

Full articulation and coverage for oversized tires depend on cutting the body sheet metal. The design gives a smoother appearance and greater strength than a bolt-on flare, and it uses stainless steel hardware for a bolt-on installation. The pair is made from thick, warp-proof Dura-Flex 2000 TPO, and the matte black finish can be left as is or custom painted.

Key features

  • Individually designed for the listed Ford models
  • 3.75 inches of width and tire coverage at the rear
  • Sheet metal removal maximizes wheel articulation
  • Stainless steel hardware for an easier bolt-on installation
  • Warp-proof Dura-Flex 2000 TPO construction
  • OEM matte black finish that can be custom painted

Measuring before you cut

Cut-out rear flares work best when the cut is measured from fixed points on the body. Use the wheel center, the bottom of the door and a level line to mark the cut, then check tire fit at full compression. A cut is hard to reverse, so make the first cut conservative and remove more metal only if the tire still rubs.

Stainless steel hardware helps the flare hold up to moisture and road salt. Check the hardware and the riveted or bolted points after rough use. Tighten the hardware evenly, and recheck it once the flare has been driven through several cycles of suspension travel.

  • Mark cuts from fixed body points
  • Trim conservatively and check fit each time
  • Recheck hardware after several suspension cycles

Specifications

Brand Bushwacker
Part number 20022-11
UPC 90689103215
Position Rear
Quantity Pair
Width and coverage 3.75 inches
Material Dura-Flex 2000 TPO
Finish OEM matte black, paintable
Front pair part number 20021-11
Warranty Limited lifetime

Vehicle fitment

It fits the 1992 to 1996 Ford Bronco, 1992 to 1996 Ford F-150, 1993 to 1995 Ford F-150 Lightning, 1992 to 1996 Ford F-250, 1997 Ford F-250 HD and 1992 to 1997 Ford F-350 in those years.

The list covers the 1992 to 1997 models above only, so the Ford Super Duty trucks from 1999 on and the Bronco from 1966 to 1977 are not included. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Cut-Out flares require cutting body sheet metal at the rear wheel openings, so this is not a bolt-on-only install. Follow the installation guide for your model, and check the clearance at full suspension travel after mounting.

What’s included

The rear Cut-Out pair is the only piece in this package. The front pair is part 20021-11.

SKU: B/W20022-11 Category:

Specification

Shipping weight 13.00 lbs
Package dimensions 52.00 × 23.00 × 13.00 in
brands

Fitment

VehicleYearsTrims
Ford Bronco1992–1996Custom, Eddie Bauer, XL, XLT, XLT Lariat, XLT Nite, XLT Sport
Ford F-1501992–1996Custom, Eddie Bauer, Special, XL, XLT, XLT Lariat
Ford F-150 Lightning1993–1995All
Ford F-2501992–1996Custom, Eddie Bauer, Special, XL, XLT, XLT Lariat
Ford F-250 HD1997XL, XLT
Ford F-3501992–1997Base, Custom, Eddie Bauer, Special, XL, XLT, XLT Lariat

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Which Ford trucks are listed?

It fits the 1992 to 1996 Bronco, the 1992 to 1996 F-150, the 1993 to 1995 F-150 Lightning, the 1992 to 1996 F-250, the 1997 F-250 HD and the 1992 to 1997 F-350. Those are the only years this pair fits.

Is this a rear pair or a front pair?

This is a rear pair. The front pair is part 20021-11, so check the position and model year before choosing.

Does this pair need cutting?

Yes. Bushwacker says Cut-Out flares require cutting body sheet metal, so confirm the listed model and year and follow the installation guide before cutting.

Do I need a separate bracket kit with these flares?

Yes. Confirm that the package hardware matches your installation before cutting, and replace any missing fasteners with matching stainless steel parts.
