Overview
The Bilstein 4600 Series heavy duty shock absorber, part number 24-186056, is a 46mm monotube gas-charged shock for the 2005–2015 Toyota Tacoma in Base and Pre Runner trims. It is a rear-position, direct-fit shock with a yellow finish and 0 in of lift or drop.
Bilstein’s heavy duty monotube design moves heat from the oil into the outer surface of the shock body. A dividing piston lets the oil expand, which the company says keeps foaming and viscosity loss in check, so the shock holds full damping while temperatures climb. The tube is produced by an extrusion process meant to keep wall thickness consistent.
Key features
- Heavy duty 4600 Series rear shock with direct fit.
- 46mm monotube body.
- Gas-charged design that carries heat from the oil to the body’s outer surface.
- Dividing piston that allows the oil to expand as temperatures rise.
- Extrusion-formed tube with a tight peak-to-valley tolerance.
- Piston head that tunes compression and rebound damping on its own settings.
- Yellow finish with 0 in lift or drop listed.
Heavy duty rear shock care
A heavy duty rear shock is designed to handle extra load, which matters on a Tacoma that carries cargo, tows, or runs rough access roads. Under those conditions the oil heats up faster and the shock works harder, so inspection matters more than on a light daily driver. Check for leaks, unusual noise, and bounce after every few trips over rough ground.
When replacing the rear pair, check the springs, bushings and bump stops too. A worn bump stop or sagging spring can make a new shock work harder than it should, and that can shorten its life. Keep the old part number, BILF4-BE5-C515-H0, in your records so future orders can be matched to this unit.
- Inspect bump stops and bushings during replacement
- Check the rear springs for sag
- Note the old part number for future matching
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-186056 |
| UPC | 651860557373 |
| Shock series | 4600 Series |
| Duty | Heavy duty |
| Body | 46mm monotube |
| Charge | Gas charged |
| Position | Rear |
| Lift/drop | 0 in |
| Finish | Yellow |
| Previous part number | BILF4-BE5-C515-H0 |
Vehicle fitment
The manufacturer fitment list places this shock on the 2005–2015 Toyota Tacoma in the Base and Pre Runner trims. Confirm your vehicle’s year, model and trim before ordering.
Tacoma years outside 2005–2015, and trims other than Base and Pre Runner, are not covered by this fitment.
Installation notes
Compare the new unit’s mounting points with the original before you begin, and gather the tools the job needs. Use stands rather than a jack alone when working under the truck.
What’s included
The shock is the only item covered. Keep the previous part number BILF4-BE5-C515-H0 on hand to match older references, and confirm the contents against your original shock.
