Overview
The AirLift single needle air gauge, part number 26227, is a white face pressure gauge that reads up to 200 PSI. It has an illuminated face, a spun aluminum center and a chrome bezel. It is a universal fit, so it is not tied to a particular year, make, model or chassis.
Key features
- Single needle, white face gauge
- Reads pressures up to 200 PSI
- Illuminated face
- Spun aluminum center with a chrome bezel
Reading an air pressure gauge
An air gauge shows the pressure held in the system so you can compare it with the setting you need. Single needle gauges show one reading at a time, which keeps the display simple to read while driving or setting up. Check the gauge against a known reference before relying on it for critical adjustments.
Mounting location affects how easy the gauge is to read. A spot in the cab where the needle is visible at a glance works best, and the air line to the gauge should be routed clear of pedals and moving parts. A panel opening that fits the gauge body with some clearance keeps the mount secure over rough roads.
Illuminated faces help in low light, but the backlight is only useful if it is wired reliably. Protect the gauge from water and direct washing, and keep the lens clean so the needle stays easy to read. Recheck the mounting nut or bezel periodically for tightness.
- Mount where the needle is visible at a glance
- Route air line clear of pedals
- Clean the lens to keep the face readable
Specifications
| Brand | AirLift |
|---|---|
| Part number | 26227 |
| UPC | 70000373180 |
| Gauge type | Single needle |
| Face | White, illuminated |
| Center | Spun aluminum |
| Bezel | Chrome |
| Pressure range | Up to 200 PSI |
| Dimensions | 2 in diameter by 2 3/4 in depth |
Vehicle fitment
This gauge is a universal fit and a standalone unit, so it is not matched to a year, make or model.
Confirm your vehicle’s year, model and trim before ordering.
