Overview
The Fab Fours FF17-H4352-1 is a winch front bumper with a pre-runner guard for 2017 to 2018 Ford F-150 trucks, fitted to the Raptor. It has two-stage black powder coat and is ready for a 12,000 lb Warn ZEON winch.
The pre-runner guard adds front protection to Fab Fours’ Premium sensor winch bumper, which provides far more tire clearance. The bumper has 7/8-inch D-ring mounts, a two-piece mounting system that can be adjusted for a custom fit and Fab Fours’ integrated fog and turn lights.
This bumper is the pre-runner guard version of the Premium sensor winch range, which also includes full guard and no guard versions. Its two-piece mounting system adjusts for a custom fit with the light housings.
Key features
- Pre-runner guard
- Accepts a 12,000 lb Warn ZEON winch with a relocation bracket
- 7/8-inch D-ring mounts
- Adjustable two-piece mounting system
- Injection molded light housings
- 90mm fog and 60mm turn indicator lights included
- Two-stage black powder coat
- 3/16-inch steel construction
Pre-runner guards on the trail
A pre-runner guard sits in front of the bumper’s face and shields the grille and lower body from brush and small rocks. It sits between a full guard and no guard, keeping the design open enough for airflow and the light mounts. Choose it when front protection matters but a full guard is more than needed.
Recovery planning matters with any winch bumper. Check the frame brackets and bolts after rough trail use, and keep the winch cable, hook and fairlead in good shape. Clean the coating around the mounts to spot early rust, and touch up chips before they spread.
- Recheck bolts after the first few trail runs
- Keep winch cable free from kinks
- Look for loose light connectors after bumps
Specifications
| Brand | Fab Fours |
|---|---|
| Part number | FF17-H4352-1 |
| UPC | 5810114909 |
| Type | Winch front bumper, pre-runner guard |
| Position | Front |
| Width | Full |
| Material | 3/16-inch steel |
| Finish | Two-stage black powder coat |
| Weight | 220-250 lb |
| Fit type | Direct fit |
| Winch mount | Included (12,000 lb Warn ZEON with relocation bracket) |
| D-ring mounts | Included, 7/8-inch |
| Lights | 90mm fog and 60mm turn indicator lights included |
Vehicle fitment
Fab Fours lists FF17-H4352-1 for the 2017 to 2018 Ford F-150 (Raptor).
Earlier F-150 trucks, such as the 2015 to 2017 and 2009 to 2014 models, are not on the list. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The adjustable two-piece mounting system lets the fit be tuned on the truck. A Warn ZEON winch needs its relocation bracket, and the winch should have a fused feed.
What’s included
- Winch front bumper with pre-runner guard
- Winch mount
- 7/8-inch D-ring mounts
- 90mm fog and 60mm turn indicator lights
Not included: The winch, the relocation bracket and winch wiring.
