Overview
The TeraFlex 4403402 is a rear brake caliper kit with pads for the 2007-2018 Jeep Wrangler JK, 2018-2026 Wrangler JL and 2020-2026 Jeep Gladiator JT. It is part of the TeraFlex Delta Brake System, which TeraFlex describes as an upgrade for vehicles running oversized, heavier wheel and tire combinations that need more braking performance.
Each caliper uses an opposed 4-piston design with a high-modulus bridge. Modulus is a material’s resistance to elastic deformation under load, so a stiff bridge changes shape only slightly when the brakes are applied. The kit replaces the factory 2-piston calipers with this stiffer bridge design while keeping the same flow rate, and it suits vehicles running oversized, heavier wheel and tire combinations.
Key features
- Opposed 4-piston design with 2″ front pistons and 1.375″ rear pistons
- Same flow rate as factory 2-piston calipers, with four pistons each moving half the distance
- 4-piece bridge design: heat-treated 4140 cast steel bridges with 6061-T6 forged aluminum piston housings
- EPDM synthetic boot keeps water and contaminants away from the piston; hard-chrome piston coating reduces friction
- Built-in auto bleeding check ball, valve and spring for easier bleeding
- 1,000-hour salt spray tested zinc and E-dipped coating on the bridges and mounts, with 300,000 psi steel formed hardware
- Semi-metallic composite-resin pads and a drop-in pad design that lets pads be replaced without disassembling the caliper
Brake upgrade considerations
Caliper upgrades change how the brake system handles heat and load, so the rest of the system should be checked at the same time. Rotor diameter, hub clearance and the bridge’s clearance inside the wheel all need to work together. Brake hoses, fluid condition and pad bedding also affect how the upgraded calipers perform.
Bleeding should be done after any caliper or hose work to remove trapped air, and the fluid should be replaced when the system is opened. New pads need a proper bedding procedure before heavy towing or steep grades, and the pad surfaces should be checked for uneven wear once the brakes have been used for a few trips.
- Match rotor diameter and hub to caliper clearance
- Replace brake fluid when the system is opened
- Bed in new pads before heavy towing
Specifications
| Brand | TeraFlex |
|---|---|
| Part number | 4403402 |
| Position | Rear |
| Piston design | Opposed 4-piston; 2″ front pistons, 1.375″ rear pistons |
| Bridge material | Heat-treated 4140 cast steel |
| Piston housing material | 6061-T6 forged aluminum |
| Boot material | EPDM synthetic |
| Rotor clearance | Accepts 14″ rotors behind 17″ wheels |
| Pad compound | Composite-resin, semi-metallic |
| Fit type | Direct fit |
Vehicle fitment
It fits 2007-2018 Jeep Wrangler JK, 2018-2026 Jeep Wrangler JL and 2020-2026 Jeep Gladiator JT models. Confirm fit for your vehicle’s year, model and trim before ordering.
This kit is the rear set only; the front axle needs its own calipers. Confirm your vehicle’s year, model and trim before ordering.
What’s included
- Rear brake calipers
- Brake pads
Not included: disc brakes (rotors).
