Smittybilt Stainless Steel Door Window Channel Kit – 7497

Smittybilt

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Stainless steel door window channel kit for 1987–1995 Wrangler YJ soft tops with half doors
  • Part number S/B7497 from Smittybilt
  • Sold as a pair, with left and right channels and screws
  • Some drilling required
  • To be used with the Smittybilt Supertop 51600

Description

Overview

The Smittybilt Stainless Steel Door Window Channel Kit, part number S/B7497, is a stainless steel kit for factory soft tops with half doors on the 1987–1995 Jeep Wrangler (YJ). It covers the full YJ range from 1987 to 1995.

The kit converts early 1987 YJ soft top steel half doors to the late-model 1988–95 fastener style. It includes left and right door channels and screws. Some drilling is required, and the kit is used with the Supertop 51600.

Key features

  • Stainless steel construction
  • Left and right door channels included
  • Screws included
  • Converts early 1987 soft top half doors to the 1988–95 fastener style
  • Sold as a pair

Preparing for the conversion

Window channels guide the side glass or soft top edge on a Jeep’s half doors, so the fastener change affects how the top seals and how the doors close. Before starting, look at the existing soft top and door frames for cracked brackets, bent steel and worn fasteners. Replacing these parts first avoids working around damage later.

Drilling is the step that takes the most care. Measure twice, mark each hole with the new channels in place, and start with smaller pilot holes where possible. Remove burrs and clean metal shavings from inside the door frame so they do not work into the hinge area or scratch the paint.

Stainless steel resists rust well, but it can gall against steel fasteners if they are not matched. Use the screws in the kit rather than mixing in older hardware. Tighten fasteners evenly and check the fit of each door before the top goes back on.

Specifications

Brand Smittybilt
Part number S/B7497
Material Stainless steel
Included Left and right door channels and screws
Quantity Sold as a pair
Use Factory soft top with half doors
Compatible with Smittybilt Supertop 51600
Drilling Some drilling required
Fit Direct fit

Vehicle fitment

It fits the 1987–1995 Jeep Wrangler (YJ). Confirm fit for your vehicle’s year, model and trim before ordering.

The list does not include the Wrangler TJ, LJ, JK or JL, or the Cherokee. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Some drilling is required. The kit is used with the Supertop 51600.

What’s included

Left and right stainless steel door channels and screws.

Not included: the Supertop 51600 soft top and the half doors the kit is meant to work with.

Fitment

VehicleYearsTrims
Jeep Wrangler (YJ)1987–1995Base, Islander, Laredo, Renegade, Rio Grande, S, SE, Sahara, Sport

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does this Smittybilt kit fit a 1990 Jeep Wrangler YJ?

Yes. The kit fits the 1987–1995 Wrangler YJ, which includes 1990 models. It converts early 1987 soft top half doors to the 1988–95 fastener style, so a 1990 YJ falls within the range it covers.

Does the Smittybilt S/B7497 kit require drilling?

Yes. Some drilling is required for installation, so plan for it before you start. Mark and check each hole position against the doors and channels before drilling, and confirm the package contents match your installation.

What is the Smittybilt window channel kit meant to be used with?

It is used with the Smittybilt Supertop 51600. The kit includes left and right door channels and screws, and it is sold as a pair for factory soft tops with half doors.

How do I tell if the top seal needs replacing?

Look for gaps, torn weather stripping, or water spots on the inside of the doors after rain. A seal that no longer compresses evenly can let wind noise and water in. Replace worn seals when you convert the doors, since fresh seals sit best against new channel positions.

Should the door channels be checked after the first drive?

Yes. Recheck the screws after the first few drives, since vibration can loosen fasteners on a Wrangler. Look for rattles, uneven door gaps, or scuffs on the channel edges, and correct them before they grow into bigger problems.
