Rubicon Express Heavy-Duty Super-Flex Joint Assembly – RE3794

Rubicon Express

Shop Rubicon Express Flex Joints on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Rubicon Express RE3794 heavy-duty Super-Flex weld-on joint kit
  • UHMW-PE races and extra thick threaded insert
  • Machined end removes the snap ring and washer used on RE3791 and RE3792
  • Up to 32 degrees of misalignment; UPC 614901440959

Description

Overview

The Rubicon Express RE3794 is a heavy-duty Super-Flex joint kit for weld-on installation. It has an extra thick threaded insert for adjustment and rebuilding, and it is rated for 32 degrees of misalignment.

The joint uses UHMW-PE races, which offer impact resistance and reduced friction. Its machined end replaces the snap ring and washer found on the RE3791 and RE3792 Super-Flex assemblies.

Key features

  • Extra thick threaded insert for adjustment and rebuilding
  • UHMW-PE races for impact resistance and low friction
  • Precision machined end, with no snap ring or washer
  • 32 degrees of misalignment
  • Weld-on joint kit
  • Serviceable DOM joint

Choosing a heavy-duty joint

Heavy-duty Super-Flex joints are used where a standard joint would see larger loads or harder articulation, such as on a build that runs big tires or frequent rock crawling. Their extra thick insert gives more material to work with when adjusting preload and rebuilding, which tends to extend service life on a joint that gets used hard.

Weld-on joints depend on the housing as much as the joint itself. A sound, correctly sized tube or sleeve matters more than any single part of the kit, and the weld should be inspected for cracks after the first few hard runs. Consider the steering or suspension angle the joint will see before setting its position.

  • Check the housing for straightness before welding
  • Use a shop familiar with suspension joint welds
  • Keep a rebuild kit or tool on hand for future service
  • Inspect the boot and seal during routine checks

Specifications

Brand Rubicon Express
Part number RE3794
UPC 614901440959
Joint details Weld-on joint kit
Misalignment 32 degrees
Race material UHMW-PE
Type DOM
Maintenance Serviceable

Vehicle fitment

It is a universal fit kit, so no specific vehicle applies. The joint size and the threaded housing it goes into must match your build.

Confirm the joint size and housing on your build before ordering, since the kit is weld-on.

Installation notes

This is a weld-on kit, so it needs welding to the housing. Have the joint set up by a welder or shop familiar with suspension joints, and use the RE3773 tool when rebuilding the insert.

SKU: R/ERE3794 Category:

Specification

Shipping weight 2.40 lbs
Package dimensions 6.00 × 4.10 × 3.80 in
brands

Questions & Answers

Does the RE3794 need the snap ring and washer?

No. Its precision machined end eliminates the snap ring and washer used in the RE3791 and RE3792 assemblies. Check that your housing is compatible with this design before ordering.

What tool rebuilds the RE3794?

The RE3773 heavy-duty joint assembly tool is used to rebuild it, along with the RE3795 HD joint. Confirm the joint part number matches the tool before buying, since the tool only works on select joints.

How much misalignment does the RE3794 allow?

It allows 32 degrees of misalignment. That is the joint's angle capacity, so keep the joint within the range your steering or suspension geometry requires.

Can a heavy-duty joint be used on a stock vehicle?

It can be fitted to a stock vehicle if the housing and geometry suit it, but heavy-duty joints are most useful where stock joints wear quickly. Confirm the joint size against the existing link before welding, since the new joint changes the load path.
