Rubicon Express 4.5 Inch Extreme Duty Radius Front/Rear 4-Link Long Arm Lift Kit – No Shocks – JKR424M

Rubicon Express

Shop Rubicon Express Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 4.5-inch lift with a radius front and 4-link rear long arm system
  • Adjustable chromoly control arms with Super-Flex spherical ball joints
  • PT-Meg Super-Ride bushings and a full-width transmission crossmember
  • Designed for installation without welding
  • No shocks included; confirm fitment before ordering

Description

Overview

The Rubicon Express JKR424M is a 4.5-inch lift kit that uses a radius front and 4-link rear long arm layout. It is offered without shocks, which is the main difference from the Mono-Tube version in the same range. The kit is part of Rubicon Express’s JK suspension line and is built around adjustable chromoly upper and lower control arms with Super-Flex spherical ball joints.

The radius and 4-link design is intended to provide control without limiting articulation, and the PT-Meg Super-Ride bushings are part of that setup. The full-width transmission crossmember stiffens the chassis and supports the install. Check your vehicle before ordering.

Key features

  • 4.5-inch lift height, within the 3 to 4.99-inch range
  • Radius front and 4-link rear long arm system
  • Adjustable chromoly upper and lower control arms
  • Super-Flex spherical ball joints
  • PT-Meg Super-Ride bushings
  • Full-width transmission crossmember
  • Installs without welding
  • Optional belly pan and CNC-machined steering knuckle

Radius and 4-link geometry

A radius front and 4-link rear change how the axles locate, which affects pinion angle, steering geometry and how the wheels travel through articulation. Radius arms resist braking and acceleration forces without relying on leaf springs, which is one reason the layout appeals to owners who drive rough trails. The arms need to be installed square, since small errors show up as vibration or uneven tire wear.

Before choosing this kit, decide whether the vehicle will mostly see trail use or daily driving, because arm angles affect highway comfort. Plan the alignment and driveline check at the end of the job rather than skipping it. Keep a record of the torque values and any shims used so future service is straightforward.

Specifications

Brand Rubicon Express
Part number JKR424M
UPC 70000651268
System type Extreme-duty radius front and 4-link rear long arm lift
Lift height 4.5 inches (manufacturer range 3 to 4.99 inches)
Front arm type Radius arm or radius arm brackets
Control arms Chromoly upper and lower, adjustable
Joints Super-Flex spherical ball joints
Bushings PT-Meg Super-Ride
Shocks Not included
Made in USA

Vehicle fitment

Fit depends on your year, model and trim, so verify those before buying. This kit is sold without shocks and belongs to the JK suspension line.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

The radius arms and 4-link rear change how the axles locate, which affects pinion angle and driveline angles. An alignment and a driveline angle check should be part of the work after installation, and the steering should be checked for proper geometry.

What’s included

The included parts are the radius front and 4-link rear long arm components, chromoly control arms, Super-Flex spherical ball joints, PT-Meg Super-Ride bushings and the full-width transmission crossmember. Shocks are not included.

Not included: shock absorbers. The title specifies no shocks, so a separate set is needed to finish the suspension.

SKU: R/EJKR424M Category:

Specification

Shipping weight 308.00 lbs
Package dimensions 0.00 × 0.00 × 0.00 in
brands

Questions & Answers

Does the JKR424M include shocks?

No. The title specifies No Shocks, and the fitment details also list shocks as not included, so a shock set matched to the 4.5-inch height has to be chosen separately before the lift is complete on the vehicle.

How does this differ from the Mono-Tube version?

The JKR444M uses the same 4.5-inch radius design with Mono-Tube shocks included. This version leaves the shocks out, so the buyer chooses the shock package while the arm set stays the same across both kits.

Is welding required for installation?

No. The kit installs without welding, and the full-width transmission crossmember is part of that design. The radius arms and 4-link components are set using the included hardware.

What lift height does the JKR424M give?

It gives 4.5 inches of lift, within the 3 to 4.99-inch lift range. The radius front and 4-link rear is the arm configuration of this kit.

How often should a radius arm setup be checked after installation?

Check the bolts and bushings after the first few trail runs, then at each regular service. Look for loose hardware, clunks at the axle and uneven tire wear. Recheck the alignment whenever the front end is serviced or the arms are adjusted.
