High Lifter Products Front Forward Control Arms (Silver) – MCFFA-RNG9-S

High Lifter Products

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • High Lifter Products silver Max Clearance front forward control arms, part number HLPMCFFA-RNG9-S
  • Arched upper and lower control arms with clearance for tires up to 30 inches
  • Works with High Lifter 2-inch and 4-inch Ranger 900 lift kits
  • Fitment list covers Polaris Ranger models from 2013 to 2018
  • Front Outlaw DHT axles and BUMPER-RNG9 or similar bumpers need extra steps

Description

Overview

The High Lifter Products Max Clearance front forward control arms in silver, part number HLPMCFFA-RNG9-S, are arched upper and lower control arms for the Polaris Ranger 900 XP and other Ranger models. The arch provides the clearance needed to run tires up to 30 inches.

A Ranger without arm modifications runs tires up to 26 inches, which is small for true mud riding. These arms raise that limit and work with High Lifter’s 2-inch and 4-inch Ranger 900 lift kits. The arms are made in the USA.

Key features

  • Arched upper and lower control arms for added front clearance
  • Clearance for tires up to 30 inches
  • Works with High Lifter 2-inch and 4-inch Ranger 900 lift kits
  • Made in the USA
  • Silver finish

Matching arms to your tires

Control arm clearance is only one part of running larger tires. The tire has to clear the fender, the inner fender liner, the steering components and the bumper at full lock and full suspension travel. Rub marks on a fender or a bumper are usually the first sign that the tire is too large for the current setup.

Steering geometry also changes when tire size and arm length change. Larger tires can make steering heavier and increase the load on ball joints and tie rods. Check toe and caster after installation, and inspect the steering stop and CV boot area after the first few drives on rough ground.

  • Check tire clearance at full lock
  • Look for rub marks after the first ride
  • Inspect ball joints and tie rod ends
  • Keep spare bushings on hand for the lower arm

Specifications

Brand High Lifter Products
Part number HLPMCFFA-RNG9-S
Finish Silver
Arm type Upper and lower, arched, front forward
Tire clearance Up to 30 inches
Largest tire without arm modifications 26 inches
Compatible lift kits High Lifter 2-inch and 4-inch Ranger 900 kits
Country of manufacture USA

Vehicle fitment

It fits Polaris Ranger models from 2013 to 2018, including the Ranger 570, 6×6 800, 900 and 1000 models and their Crew, Diesel and XP versions. Confirm fit for your vehicle’s year, model and trim before ordering.

Front Outlaw DHT axles and certain bumpers need the extra steps described below. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

If you run Front Outlaw DHT axles with this kit, add the Polaris Steering Stop Kit (part RANGER-SSK) to avoid clearance problems at the CV boot.

Check the ball joints, bearings and bushings for wear before installation, and replace any that are worn. High Lifter lists bearing part BJP-3 for the ball joints and bushing part WBK-25-1628 for the lower control arm, and part number BK-50-1076 is also referenced.

If you plan to run these arms with bumper BUMPER-RNG9 or a similar bumper, the bumper must be modified, cut or trimmed to clear tires 28 inches or taller.

What’s included

The silver front forward control arms.

Not included: the steering stop kit, bearings and bushings covered in the installation steps, which are sold as separate parts.

Fitment

VehicleYearsTrims
Polaris Ranger 5702015–2016Full-Size Base
Polaris Ranger 570 Crew2015EPS Base, EPS Full-Size Base
Polaris Ranger 570-4 Crew2016Base
Polaris Ranger 570-6 Crew2016Base
Polaris Ranger 6x6 8002016Base
Polaris Ranger 900 Crew2014–2015Base, EPS Base
Polaris Ranger 900 XP2013–2017Base, EPS Base
Polaris Ranger 900-5 Crew2016EPS Base
Polaris Ranger 900-6 Crew2016Base
Polaris Ranger Crew Diesel2016–2018Base
Polaris Ranger Crew XP 10002017–2018Base, EPS Base, EPS Northstar HVAC Edition Base
Polaris Ranger Crew XP 9002017–2018Base, EPS Base
Polaris Ranger Diesel2015–2018Base, HST Base
Polaris Ranger Diesel Crew2015Base
Polaris Ranger XP 10002017Base, EPS Base, EPS Northstar HVAC Edition Base
Polaris Ranger XP 9002018Base

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

What is the largest tire a Ranger can run without arm modifications?

High Lifter says 26 inches is the largest a Ranger can safely run without arm modifications. These silver arms provide clearance for tires up to 30 inches.

Do I need a steering stop kit with these arms?

Only with Front Outlaw DHT axles. High Lifter says to add the Polaris Steering Stop Kit, part RANGER-SSK, to avoid clearance issues at the CV boot.

Will these arms work with a bumper?

They can, but High Lifter says BUMPER-RNG9 or a similar bumper must be modified, cut or trimmed to clear tires 28 inches or taller.

Which Ranger models do these arms fit?

Polaris Ranger 570, 6x6 800, 900 and 1000 models from 2013 to 2018 are covered, including Crew, Diesel and XP versions. For 2019 and later Ranger models, check the year, model and trim before ordering.

Do arms like these change steering or ride quality?

Yes, in some ways. Reshaped control arms change suspension geometry, so caster, toe and steering feel can shift. Have the alignment checked after installation, and inspect tie rod ends and boots during regular service.
